Thread: Odd noise coming from the horizontally placed fans

  1. 11-16-2009, 01:08 PM #1
    zalbard
    zalbard is offline
    I am Xtreme
    Join Date
    Dec 2008
    Location
    France
    Posts
    9,060

    Odd noise coming from the horizontally placed fans

    Houston, we have a problem.
    I have quite a few fans in my second rig, and only two of them are horizontal.
    At first the one at the top of the case started making a weird sound sometimes. Hard to describe it. Reminds me of the pump noise a bit. I could stop it, then let it run again, and it would be silent. I got tired of this and removed it.
    Now the same started happening with the second fan. The problem is that this second horizontally placed fan is on my graphics card, and I cannot really replace it.
    Is there any idea what I can do to fix it?
    Any help would be much appreciated. Thanks!
    Last edited by zalbard; 11-17-2009 at 08:16 AM.
    Donate to XS forums
    Quote Originally Posted by jayhall0315 View Post
    If you are really extreme, you never let informed facts or the scientific method hold you back from your journey to the wrong answer.
    Reply With Quote Reply With Quote
  2. 11-16-2009, 01:30 PM #2
    zanzabar
    zanzabar is offline
    I am Xtreme zanzabar's Avatar
    Join Date
    Jul 2007
    Location
    SF bay area, CA
    Posts
    15,871
    what kind of fan is it, u have to use a 2 ball bearing as if u try to use a sleeved motor it will do what u are talking about
    5930k, R5E, samsung 8GBx4 d-die, vega 56, wd gold 8TB, wd 4TB red, 2TB raid1 wd blue 5400
    samsung 840 evo 500GB, HP EX 1TB NVME , CM690II, swiftech h220, corsair 750hxi
    Reply With Quote Reply With Quote
  3. 11-16-2009, 01:38 PM #3
    zalbard
    zalbard is offline
    I am Xtreme
    Join Date
    Dec 2008
    Location
    France
    Posts
    9,060
    Erm, just a normal fan... Similar to



    No clue if it tells you anything!
    Donate to XS forums
    Quote Originally Posted by jayhall0315 View Post
    If you are really extreme, you never let informed facts or the scientific method hold you back from your journey to the wrong answer.
    Reply With Quote Reply With Quote
  4. 11-16-2009, 02:06 PM #4
    zanzabar
    zanzabar is offline
    I am Xtreme zanzabar's Avatar
    Join Date
    Jul 2007
    Location
    SF bay area, CA
    Posts
    15,871
    look at the back it should say what kind of motor it has on the sticker
    5930k, R5E, samsung 8GBx4 d-die, vega 56, wd gold 8TB, wd 4TB red, 2TB raid1 wd blue 5400
    samsung 840 evo 500GB, HP EX 1TB NVME , CM690II, swiftech h220, corsair 750hxi
    Reply With Quote Reply With Quote
  5. 11-16-2009, 02:10 PM #5
    zalbard
    zalbard is offline
    I am Xtreme
    Join Date
    Dec 2008
    Location
    France
    Posts
    9,060
    Will do. How am I supposed to check this for the GPU fan, though?
    Donate to XS forums
    Quote Originally Posted by jayhall0315 View Post
    If you are really extreme, you never let informed facts or the scientific method hold you back from your journey to the wrong answer.
    Reply With Quote Reply With Quote
  6. 11-16-2009, 02:27 PM #6
    zanzabar
    zanzabar is offline
    I am Xtreme zanzabar's Avatar
    Join Date
    Jul 2007
    Location
    SF bay area, CA
    Posts
    15,871
    oh i thought that u meant on a replaced HS
    5930k, R5E, samsung 8GBx4 d-die, vega 56, wd gold 8TB, wd 4TB red, 2TB raid1 wd blue 5400
    samsung 840 evo 500GB, HP EX 1TB NVME , CM690II, swiftech h220, corsair 750hxi
    Reply With Quote Reply With Quote
  7. 11-16-2009, 02:30 PM #7
    zalbard
    zalbard is offline
    I am Xtreme
    Join Date
    Dec 2008
    Location
    France
    Posts
    9,060
    The first fan that went bad was similar to the one I linked above.
    The GPU fan is this one:

    Donate to XS forums
    Quote Originally Posted by jayhall0315 View Post
    If you are really extreme, you never let informed facts or the scientific method hold you back from your journey to the wrong answer.
    Reply With Quote Reply With Quote
  8. 11-17-2009, 08:12 AM #8
    zalbard
    zalbard is offline
    I am Xtreme
    Join Date
    Dec 2008
    Location
    France
    Posts
    9,060
    Any more ideas what to do with the GPU heatsink fan from the picture above?
    What can be causing the noise anyway? It doesn't have the noise all the time... Can suddenly start and stop... And it's constantly spinning for sure.
    Donate to XS forums
    Quote Originally Posted by jayhall0315 View Post
    If you are really extreme, you never let informed facts or the scientific method hold you back from your journey to the wrong answer.
    Reply With Quote Reply With Quote
  9. 11-17-2009, 12:37 PM #9
    wez
    wez is offline
    Xtreme Addict
    Join Date
    May 2004
    Location
    Aland Islands, Finland
    Posts
    1,137
    Quote Originally Posted by zalbard View Post
    Any more ideas what to do with the GPU heatsink fan from the picture above?
    What can be causing the noise anyway? It doesn't have the noise all the time... Can suddenly start and stop... And it's constantly spinning for sure.
    Sounds like its starting to give up. I'd buy one of those pci-slot fans, pull out the fan and glue it in place on the gfx card, should work
    Asus Crosshair IV Extreme
    AMD FX-8350
    AMD ref. HD 6950 2Gb x 2
    4x4Gb HyperX T1
    Corsair AX1200
    3 x Alphacool triple, 2 x Alphacool ATXP 6970/50, EK D5 dual top, EK Supreme HF
    Reply With Quote Reply With Quote
  10. 11-17-2009, 02:28 PM #10
    jim0ne
    jim0ne is offline
    Xtreme Member
    Join Date
    Sep 2006
    Posts
    140
    Quote Originally Posted by wez View Post
    Sounds like its starting to give up. I'd buy one of those pci-slot fans, pull out the fan and glue it in place on the gfx card, should work
    This. I had that same problem awhile ago when i had an aftermarket cooler on my gpu. It will make sound when it gets off balance and starts spinning weird and one day it die out soon afterwards.
    Reply With Quote Reply With Quote
  11. 11-17-2009, 02:39 PM #11
    zalbard
    zalbard is offline
    I am Xtreme
    Join Date
    Dec 2008
    Location
    France
    Posts
    9,060
    Meh, thought so.
    It's kind of funny that horizontally placed fans are dying first, though. Interesting observation.
    Ah well, going to look for a replacement!
    Thanks everyone for your feedback! Even though we couldn't find a fix, but it is still very much appreciated.
    Donate to XS forums
    Quote Originally Posted by jayhall0315 View Post
    If you are really extreme, you never let informed facts or the scientific method hold you back from your journey to the wrong answer.
    Reply With Quote Reply With Quote
  12. 11-21-2009, 01:24 PM #12
    BababooeyHTJ
    BababooeyHTJ is offline
    Xtreme Mentor
    Join Date
    May 2008
    Posts
    2,554
    This might be worth a shot.
    Reply With Quote Reply With Quote
  13. 11-25-2009, 09:36 PM #13
    Serpentarius
    Serpentarius is offline
    Xtreme Addict
    Join Date
    Jun 2007
    Posts
    2,064
    sleeved bearing fans ........ assumed
    they normally meant to be place on vertical ... if placed on horizontal, the lubricant doesn't retained correctly and thus causes extra noises ... sometimes, even burning smell may occur ... not to mention it shortens the lifetime of the fan

    get ball bearing fans if you wish to place the fan horizontally
    Reply With Quote Reply With Quote
