04-06-2011, 11:56 AM
Splave

Ive been benching @ 1.68v 5.6ghz on ambient air cooling and chip is still as fast as the day I got it :) If it burns up rma it
04-06-2011, 05:32 PM
LardArse

Here is a double edged sword, tip for maximizing bclk/yet the wrong setting can produce CPU sensitivities to '00' at resets etc :

http://g.imagehost.org/0393/skew.jpg

First set Skew driving voltage to 1.04v, set bclk skew to 0 , rest of skew to auto and start pushing bclk to find limit.
next set Skew driving voltage to 1.04v, set bclk skew to -8 , rest of skew to auto and start pushing bclk to find limit.
next set Skew driving voltage to 1.04v, set bclk skew to -12 , rest of skew to auto and start pushing bclk to find limit.
if bclk is increasing going to -12 then slowly lower skew driving voltage from 1.04v to try to max bclk again.

for reducing bclk First set bclk skew to 0 , set Skew driving voltage to 1.04v,rest of skew to auto and start rewducing bclk to find limit.
next set bclk skew to +12 , set Skew driving voltage to 1.04v,rest of skew to auto and start rewducing bclk to find limit.
if bclk is redusing going to +12 then slowly increase skew driving voltage from 1.04v to try to reduce bclk again.
04-06-2011, 05:50 PM
Dumo

Quote:

Originally Posted by LardArse

Here is a double edged sword, tip for maximizing bclk/yet the wrong setting can produce CPU sensitivities to '00' at resets etc :

Thanks for info..got a lot of "00" playing with 1303, good thing it wasn't the perpetual "00":)
04-06-2011, 06:20 PM
l0ud_sil3nc3

Quote:

Originally Posted by LardArse

Here is a double edged sword, tip for maximizing bclk/yet the wrong setting can produce CPU sensitivities to '00' at resets etc :

http://g.imagehost.org/0393/skew.jpg

First set Skew driving voltage to 1.04v, set bclk skew to 0 , rest of skew to auto and start pushing bclk to find limit.
next set Skew driving voltage to 1.04v, set bclk skew to -8 , rest of skew to auto and start pushing bclk to find limit.
next set Skew driving voltage to 1.04v, set bclk skew to -12 , rest of skew to auto and start pushing bclk to find limit.
if bclk is increasing going to -12 then slowly lower skew driving voltage from 1.04v to try to max bclk again.

for reducing bclk First set bclk skew to 0 , set Skew driving voltage to 1.04v,rest of skew to auto and start rewducing bclk to find limit.
next set bclk skew to +12 , set Skew driving voltage to 1.04v,rest of skew to auto and start rewducing bclk to find limit.
if bclk is redusing going to +12 then slowly increase skew driving voltage from 1.04v to try to reduce bclk again.

thanks sham:up:
04-07-2011, 06:45 AM
sfxs

So I pretty much gave up on 5Ghz+ for daily use :shakes:. Not worth how much I had to bump the voltage to get it stable at all; too high temps for my liking too.

I am working on stability at:
i7-2600k @ 4.8 HT off, 1.350v

I know 1.325v is unstable (small fft fail < 1 minute).
4x4GB @ 1866Mhz, 8-9-8-24-2T, 1.625v

I know 1.600v is unstable (blend fail < 1 minute).

At the above settings I ran blend overnight; 3 of 4 threads were still running after 8+ hours; one thread failed with a rounding error after ~2hr.

I am testing a bump in VCCIO to 1.07500 currently - does anyone have any insight as to where I should look for additional stability at these settings?

Thanks,
-sfxs
04-07-2011, 08:17 AM
jcniest5

Quote:

Originally Posted by LardArse

...the wrong setting can produce CPU sensitivities to '00' at resets etc :

Is this dangerous or a can Reset CMOS resolve this problem? I might try it if it's not dangerous.
04-07-2011, 08:19 AM
LardArse

Quote:

Originally Posted by jcniest5

Is this dangerous or a can Reset CMOS would resolve this problem? I might try it if it's not dangerous.

reset cmos and you're good
04-07-2011, 10:45 AM
jcniest5

Quote:

Originally Posted by LardArse

reset cmos and you're good

Will try it later then. Thanks!
04-07-2011, 11:36 AM
Loch

Hi, I'm experiencing some problems here, i get a double post everything i touch the bclk. Is there any option or bios to get rid of the double post?

Am using bios 1303
04-07-2011, 09:23 PM
LardArse

Quote:

Originally Posted by Loch

Hi, I'm experiencing some problems here, i get a double post everything i touch the bclk. Is there any option or bios to get rid of the double post?

Am using bios 1303

its a limitation of using the management engine of PCH to change the bclks, every change a 'shutdown' and power on, i think partly because the bclk range of cpu isnt able to deviate far from bootup frequency.
04-07-2011, 09:39 PM
l0ud_sil3nc3

Quote:

Originally Posted by LardArse

its a limitation of using the management engine of PCH to change the bclks, every change a 'shutdown' and power on, i think partly because the bclk range of cpu isnt able to deviate far from bootup frequency.

makes sense because this does not happen when you are just changing the multi, and I have only noticed it on massive bclk changes that stray away from the default bclk i.e. 100>105
04-07-2011, 10:00 PM
subzero 1979

hello guys i want to know for k series processor
overclock take enable intel speedstep tech and turbo mode or take it off?????
04-07-2011, 10:02 PM
l0ud_sil3nc3

Quote:

Originally Posted by subzero 1979

hello guys i want to know for k series processor
overclock take enable intel speedstep tech and turbo mode or take it off?????

leave turbo on and turn off speedstep and c1e, c3 and c6
04-07-2011, 10:06 PM
subzero 1979

thank you
04-07-2011, 10:28 PM
Loch

Quote:

Originally Posted by LardArse

its a limitation of using the management engine of PCH to change the bclks, every change a 'shutdown' and power on, i think partly because the bclk range of cpu isnt able to deviate far from bootup frequency.

Thanks for replying but I think u got me wrong. What I meant was I'll get a double post every time I shut down n power up. Yes I know the mb will do double post after I change bclk in bios n save. But is it normal that every startup upon shutdown will do a double post?
04-08-2011, 12:13 AM
aoch88

Quote:

Originally Posted by sfxs

I am testing a bump in VCCIO to 1.07500 currently - does anyone have any insight as to where I should look for additional stability at these settings?

Thanks,
-sfxs

What does VCCIO do? How about CPU VTT? Does it impact the Vcore or stability like in the case of LGA1366?
04-08-2011, 12:23 AM
sfxs

Quote:

Originally Posted by aoch88

What does VCCIO do? How about CPU VTT? Does it impact the Vcore or stability like in the case of LGA1366?

I have mostly been following this information posted by an ASUS rep.

According to that, VCCIO is involved in the memory controller. As I was pushing the ram a bit past spec (not much, but it is 4x4GB - much harder to OC), I decided to up it a bit. I was erroring/crashing linx in seconds before I upped it. After, I ran about 15 minutes or so and saw a couple 101 bsod's so upped the vcore too. I ran 6hr small fft and 20 pass 14GB working set linx today without issues, as well as some 3dMark 11 Extreme passes. I am about to set up blend and go to sleep.

TLDR: VCCIO seems to help if you are pushing ram very hard or have 4 sticks instead of 2. My current voltages etc. are in sig. - everything else is on Auto; PLL and LLC as well.

UPDATE:

Quote:

[Apr 8 06:52]FATAL ERROR: Rounding was 0.4981384277, expected less than 0.4
[Apr 8 06:52]Torture Test completed 205 tests in 2 hours, 17 minutes - 1 errors, 0 warnings.

:upset:

-sfxs
04-08-2011, 08:05 AM
subzero 1979

when i set the voltage to 1.55 i take cpu overvoltage error
what it means?????
how i can to bypass this error
ty
04-08-2011, 08:16 AM
Leeghoofd

set the Vcore readout to ignore in the Bios monitor tab...
04-08-2011, 09:00 AM
stasio

ASUS MaximusIV-Extreme BIOS 1204

ftp://ftp.asus.com.tw/pub/ASUS/mb/LGA1155...e-ASUS-1204.zip
04-08-2011, 09:27 AM
LardArse

Quote:

Originally Posted by Loch

Thanks for replying but I think u got me wrong. What I meant was I'll get a double post every time I shut down n power up. Yes I know the mb will do double post after I change bclk in bios n save. But is it normal that every startup upon shutdown will do a double post?

yes , its normal, if bclk is some steps from 100.0 ( i cant remember how many)
04-08-2011, 09:28 AM
subzero 1979

i have 1303 its older this one???
04-08-2011, 10:17 AM
jcniest5

Quote:

Originally Posted by subzero 1979

i have 1303 its older this one???

No, 1204 is older than 1303.
04-08-2011, 10:23 AM
Loch

Quote:

Originally Posted by LardArse

yes , its normal, if bclk is some steps from 100.0 ( i cant remember how many)

Oh I see, I'm running 106 bclk completely stable, jus the double boot every startup is annoying. Y do some of the others running higher bclk got no double post? Does this has anything to do with the mb?
04-08-2011, 10:35 AM
chew*

1 Attachment(s)

Quote:

Originally Posted by LardArse

Here is a double edged sword, tip for maximizing bclk/yet the wrong setting can produce CPU sensitivities to '00' at resets etc :

http://g.imagehost.org/0393/skew.jpg

First set Skew driving voltage to 1.04v, set bclk skew to 0 , rest of skew to auto and start pushing bclk to find limit.
next set Skew driving voltage to 1.04v, set bclk skew to -8 , rest of skew to auto and start pushing bclk to find limit.
next set Skew driving voltage to 1.04v, set bclk skew to -12 , rest of skew to auto and start pushing bclk to find limit.
if bclk is increasing going to -12 then slowly lower skew driving voltage from 1.04v to try to max bclk again.

for reducing bclk First set bclk skew to 0 , set Skew driving voltage to 1.04v,rest of skew to auto and start rewducing bclk to find limit.
next set bclk skew to +12 , set Skew driving voltage to 1.04v,rest of skew to auto and start rewducing bclk to find limit.
if bclk is redusing going to +12 then slowly increase skew driving voltage from 1.04v to try to reduce bclk again.

Not to say this doesn't work but lets says all cpu's react diff?

I played with every skew setting on one of my chips. The lower 4 do not have ill effects. The top 2 ( voltage + bclk skew ) however no matter what setting or combo fail to post.

Leaving them alone =
04-08-2011, 11:46 AM
biship

Just got this beast. Anyone know the diff between the 82583 and the 82579 Intel Lan controllers?
04-08-2011, 09:02 PM
cstkl1

Quote:

Originally Posted by chew*

Not to say this doesn't work but lets says all cpu's react diff?

I played with every skew setting on one of my chips. The lower 4 do not have ill effects. The top 2 ( voltage + bclk skew ) however no matter what setting or combo fail to post.

Leaving them alone =

nice

try running 3dmark06 gpu test sm2 and sm3 only 10 loops

this is where i need to adjust the skews.
04-08-2011, 09:05 PM
LardArse

chew at 110 bclk i can tell you the skew is not at 'default' when left alone.
04-08-2011, 09:26 PM
l0ud_sil3nc3

is 1303 still the newest bios?
04-08-2011, 11:55 PM
kpablo

What is new in the 1303? From 1204?
04-09-2011, 01:37 AM
cstkl1

Quote:

Originally Posted by kpablo

What is new in the 1303? From 1204?

1298
Fxed 3 dram timings
1303
Usb fixed
C6 state limit
No more option to change nf200 voltage

Thats about it i think
04-09-2011, 02:59 AM
subzero 1979

nice mobo but i have a crappy cpu only 53x :(
04-09-2011, 09:00 AM
jcniest5

Quote:

Originally Posted by subzero 1979

nice mobo but i have a crappy cpu only 53x :(

That's not bad...mine won't even do 51x!!!:down:
04-09-2011, 03:42 PM
chew*

Quote:

Originally Posted by LardArse

chew at 110 bclk i can tell you the skew is not at 'default' when left alone.

Yes i understand that shammy, but it seems the value it is at whatever it may be can not be set manually? Any attempt to set it manually fails post :shrug: Maybe my chip is just mentally challenged though.
04-09-2011, 03:46 PM
chew*

1 Attachment(s)

Quote:

Originally Posted by cstkl1

nice

try running 3dmark06 gpu test sm2 and sm3 only 10 loops

this is where i need to adjust the skews.

I can run any test at that bclk. 32m strikes a nerve on this board more than anything i can run 3d......The other tests don't mean much tbh but i always test above and beyond ;)
04-09-2011, 04:25 PM
l0ud_sil3nc3

Quote:

Originally Posted by chew*

I can run any test at that bclk. 32m strikes a nerve on this board more than anything i can run 3d......The other tests don't mean much tbh but i always test above and beyond ;)

:clap:

clean run, still on the GSkills?
04-09-2011, 06:30 PM
jcniest5

Quote:

Originally Posted by chew*

I can run any test at that bclk. 32m strikes a nerve on this board more than anything i can run 3d......The other tests don't mean much tbh but i always test above and beyond ;)

Where did you get CPU-Z 1.57.2? The latest I see is 1.57.1 (ROG's Edition).
04-09-2011, 06:32 PM
jcniest5

Quote:

Originally Posted by subzero 1979

nice mobo but i have a crappy cpu only 53x :(

Quote:

Originally Posted by jcniest5

That's not bad...mine won't even do 51x!!!:down:

And now (the latest I have) is not even stable 46x! I'm going berserk :( :( :(
04-09-2011, 07:19 PM
Dumo

Quote:

Originally Posted by jcniest5

And now (the latest I have) is not even stable 46x! I'm going berserk :( :( :(

How to find max multi...

Try this with 51X to start, doesn't matter what air cooling you use..

http://img857.imageshack.us/img857/5...enshot015q.jpg

http://img19.imageshack.us/img19/223...nshot016om.jpg

http://img541.imageshack.us/img541/3...nshot017os.jpg

My cpu maxed @ 56X

57X will stop @ blinking cursor and AE on post code reader. Sometimes a cpu can boot all the way to windows splash/bars and freeze...that means limitation of multi has been reached..

http://img151.imageshack.us/img151/3...enshot014k.jpg
04-09-2011, 07:56 PM
owikh84

Guys, should i reject this board? I sent my B2 for B3 swap but it came back like this...

http://i458.photobucket.com/albums/q...K/DSC_0025.jpg http://i458.photobucket.com/albums/q...K/DSC_0030.jpg
http://i458.photobucket.com/albums/q...K/DSC_0032.jpg
http://i458.photobucket.com/albums/q...K/DSC_0034.jpg
so basically Asus just desolders the old B2 chipset and resolder B3 on old board, forget about scratch here and there, missing accessories and return it to customers. Is this the so-called B3 one to one exchange program?
04-09-2011, 08:25 PM
Praz

Quote:

Originally Posted by jcniest5

Where did you get CPU-Z 1.57.2? The latest I see is 1.57.1 (ROG's Edition).

ftp://ftp.asus.com.tw/pub/ASUS/misc/...asus_setup.zip
04-11-2011, 02:48 AM
newhit

Quote:

Originally Posted by owikh84

..........Guys, should i reject this board? I sent my B2 for B3 swap but it came back like this...

I took delivery of a B3 board which was well used. There was heatsink dust and heatsink scratches on it, screw marks, etc. It was DOA anyway and had to be RMA'ed
04-11-2011, 03:17 AM
cstkl1

lol sham

i have one cpu that loves + on bclk skew for higher bclk L051Axxx
and another that likes - on bclk skew for higher bclk 3103Bxxx

vcore for vcore etc all voltages on both are same
04-11-2011, 03:26 AM
Falkentyne

Kevin !!!
REJECT that damaged board immediately! demand a NEW one!!
04-11-2011, 03:40 AM
owikh84

Quote:

Originally Posted by newhit

I took delivery of a B3 board which was well used. There was heatsink dust and heatsink scratches on it, screw marks, etc. It was DOA anyway and had to be RMA'ed

So i am not alone with revived board. I duno whether it is DOA or not just don't wanna touch it.

Quote:

Originally Posted by Falkentyne

Kevin !!!
REJECT that damaged board immediately! demand a NEW one!!

yes of course I will do that, because this is a FLAWED one to one swap program committed by ASSus. They are supposed to give me a BRAND NEW board without question asked.
04-11-2011, 06:43 AM
newhit

Quote:

Originally Posted by owikh84

So i am not alone with revived board. I duno whether it is DOA or not just don't wanna touch it.

Yeah, send it right back.:(:down:

It didn't matter to me because the thing was well used and useless. I only tried it in the first place to just get some "early learning" in..........Yelp! Some learning curve, more like "flat lining" :shakes::down:
04-11-2011, 06:54 AM
owikh84

Quote:

Originally Posted by newhit

Yeah, send it right back.:(:down:

It didn't matter to me because the thing was well used and useless. I only tried it in the first place to just get some "early learning" in..........Yelp! Some learning curve, more like "flat lining" :shakes::down:

what a bad first impression u had there man. :(
ASSus will do anything as long as there has a business for them. They never care about their customer feeling instead only concentrate on doing sales. The "desoldering-resoldering" B3 chipset took 3 weeks + which shows they are slowpoke and inefficient in handling such an after sales service. Bottom-notch service :down:
04-11-2011, 06:59 AM
nijel

3 weeks +... they gotta stock some well used B2 boards first to start shipping them back as a B3 boards you know, ha-ha
04-11-2011, 07:10 AM
owikh84

Quote:

Originally Posted by nijel

3 weeks +... they gotta stock some well used B2 boards first to start shipping them back as a B3 boards you know, ha-ha

No doubt this is what's happening right now.
B2 boards were revamped to B3, without checking the bent pins, scratches here and there.
I was wondering whether they do pre-test on this resoldered B3 board or not before returning to buyers and becomes DOA. :shakes:
04-11-2011, 08:28 AM
l0ud_sil3nc3

makes me glad I bought a bnib b3 with no problems:D

I would definitely return those turd looking boards asap and demand a bnib product just like you bought originally.
04-11-2011, 11:05 AM
cstkl1

crap i just screwed up my bios 1

it wont overclock bclk anymore
aka wont do the shutdown restart thingy anymore
even when flashing bios
since i can only use from 1204-1298 and 1303 atm

even using 2nd bios at bios 6xx and with it reflashing the irog firmware
1st bios is a no go

anybody got a solution??
04-11-2011, 11:09 AM
quake6

You probably pressed Q-Reset button? When you do that, it screws bioses power management part inside the bios and you have to buy a new bios chip or reprogram it with EEPROM.

No other way to fix it
04-11-2011, 11:21 AM
cstkl1

Quote:

Originally Posted by quake6

You probably pressed Q-Reset button? When you do that, it screws bioses power management part inside the bios and you have to buy a new bios chip or reprogram it with EEPROM.

No other way to fix it

eh 2nd bios works fine

q-reset

u mean the clear cmos?? at the i/o panel??

cause never pressed the reset or power button on the mobo ever
04-11-2011, 11:22 AM
quake6

No, this one
http://farm6.static.flickr.com/5041/...eb3bd041d9.jpg

It screws only one bios and that is the one which was used when you pressed it
04-11-2011, 11:23 AM
cstkl1

nope never pressed that.. where the heck is that.
04-11-2011, 11:26 AM
quake6

Then you didn't followed the instruction on how to flash bios. That is two known reason when you can't change bclk. Maybe you did something else, but that is what I know as I pressed q-reset and got the new bios chips from ASUS
04-11-2011, 11:28 AM
PolRoger

owikh84...

The condition of that RMA exchanged board is kind of "bogus"!!

I guess the best way to ensure a new board is to do an RMA/exchange with the original retailer. It so happened that B3's were already out when I purchased mine but I still have a dead TP67XE that I'm waiting to exchange at Micro Center when ever they get the B3 versions back in stock.

I also have a perfectly functioning B2 ASRock Pro Fat that I bought second hand on the classifieds and the only way to get a B3 is to RMA direct with ASRock. Now I'm wondering what kind/condition board I'll end up with when (if) I RMA it?
04-11-2011, 11:36 AM
cstkl1

Quote:

Originally Posted by quake6

Then you didn't followed the instruction on how to flash bios. That is two known reason when you can't change bclk. Maybe you did something else, but that is what I know as I pressed q-reset and got the new bios chips from ASUS

it happened after i change a proc.
and its farnny 14 proc change no issue at the 15th hit home run
hmm was needing a b3 replacement anyway.

darn this b2 was going quite strong so far.
04-11-2011, 11:43 AM
cstkl1

[quotw]

new bios
http://www.freefilehosting.net/maxim...reme-asus-1485

Changed some memory stuff
added Memory timings:
I/O Latency + RTL Offset

can play with it with oc memory... [/quote]
04-11-2011, 04:10 PM
seba84_2005

I have voltage problem with stock settings on 2600K

once in idle voltage automatically drop to 0.9v. Now i have all the time 1.264v

http://img202.imageshack.us/img202/9823/beztytuuidw.png

I check many bios and still to be high voltage in idle :shrug:
What it might be the reason?
04-11-2011, 05:08 PM
Falkentyne

Quote:

Originally Posted by cstkl1

crap i just screwed up my bios 1

it wont overclock bclk anymore
aka wont do the shutdown restart thingy anymore
even when flashing bios
since i can only use from 1204-1298 and 1303 atm

even using 2nd bios at bios 6xx and with it reflashing the irog firmware
1st bios is a no go

anybody got a solution??

If clearing CMOS with the power supply switch turned off won't work, then the ONLY thing you can do is remove, check cpu pins again ,and reinsert. This helped someone else...
04-12-2011, 12:55 AM
jcniest5

Quote:

Originally Posted by cstkl1

[quotw]

new bios
http://www.freefilehosting.net/maxim...reme-asus-1485

Changed some memory stuff
added Memory timings:
I/O Latency + RTL Offset

can play with it with oc memory...

[/QUOTE]

What kind of site is that? I cannot download the file...asking too many questions.
04-12-2011, 01:09 AM
stasio

Quote:

Originally Posted by jcniest5

What kind of site is that? I cannot download the file...asking too many questions.

http://91.121.148.119/downloads/BIOS...-ASUS-1485.ROM
04-12-2011, 08:29 AM
noobzed

Hi guys, is it possible to flash the bios1 while runing on bios2 ?

Also, do you get weird usb 3.0 ports behaviour ?
In fact, I lost 4 usb 3.0 ports, after a normal cold boot like everyday, tried many things to solve issue, finally I switched bios ( with the little red button ) and magical ports came to life ... any explications ?

PS: english not my maternal language.
04-12-2011, 08:45 AM
seba84_2005

You can't flash bios 1 if You runing on bios 2. But You can flashback any bios with USB ROG Connect.

1: Download any bios:
2: Rename to m4e.ROM
3: Paste to USB Pendrive bios file and turn off PC
4: Plug pendrive to USB ROG Connect
5: Pres and hold over 5 sec ROG button. You can see the bios 1 led is blinking.
6: Wait to finish (the bios led stop blinking)

I flashback from bios 1303 to 1101 etc.
04-12-2011, 08:59 AM
noobzed

:up:
04-12-2011, 12:27 PM
cstkl1

thnks seba always wondered about that
thought it could rescue my bios 1 but didnt.
04-12-2011, 01:13 PM
Falkentyne

cstk1: Did you see my post?
04-12-2011, 05:52 PM
m4gg0t

I have this board waiting to get my new case before I put it in. Need help getting to 4.8ghz.
04-12-2011, 11:13 PM
jcniest5

Quote:

Originally Posted by m4gg0t

I have this board waiting to get my new case before I put it in. Need help getting to 4.8ghz.

Unless you got a crappy CPU, just up the bclk to 100 and multiplier to 48x and set vcore to 1.450v to start with. If it's stable at speed, then you can try to lower the vcore for a cooler running CPU. What I find to be a little more comforting is use CPU Level Up to 4.6Ghz as the initial OC. Once it passed 12 hours of Prime95 at that speed, then do the manual OCing as I stated in the first two sentences.
04-12-2011, 11:32 PM
aoch88

Any ideas what are the specific voltages that has to be increased for 5Ghz overclock apart from the Vcore? Most of them are left "AUTO" so some tweaking might probably help?
04-13-2011, 12:43 AM
cstkl1

Quote:

Originally Posted by Falkentyne

cstk1: Did you see my post?

yeah i did do that with 3 procs lol

no diff. this issue happened in bios after a series of changes and adding thumbdrives etc etc etc. with a newly installed cpu

i've taken ure suggestion and even when further by changing 3 different cpu's still nothing

bios 2 works fine
04-13-2011, 05:56 AM
Splave

I can confirm that boards not running hyper at 2133 7-7-7 are just not good hyper. Popped some new cas7 2000 doms in and works like a charm up to 1100 7-7-7 for 32m :D
04-13-2011, 09:19 AM
l0ud_sil3nc3

Quote:

Originally Posted by Splave

I can confirm that boards not running hyper at 2133 7-7-7 are just not good hyper. Popped some new cas7 2000 doms in and works like a charm up to 1100 7-7-7 for 32m :D

really so you just need the dank, no schwiggity schwoo, I bet GTX2's would do great then.

I have a set of STT 2000c7 that I am trying to sell and they are new, is it worth keeping them and trying them out?
04-13-2011, 09:29 AM
Splave

Quote:

Originally Posted by l0ud_sil3nc3

really so you just need the dank, no schwiggity schwoo, I bet GTX2's would do great then.

I have a set of STT 2000c7 that I am trying to sell and they are new, is it worth keeping them and trying them out?

probably not worth keeping as I havent heard of success with STT. I have the 2000c7 project-X and it is a no go for 32m
04-13-2011, 09:36 AM
seba84_2005

I make wallpapers ;) how do you like?

http://img69.imageshack.us/img69/284...seba842005.jpg
04-13-2011, 10:07 AM
l0ud_sil3nc3

Quote:

Originally Posted by Splave

probably not worth keeping as I havent heard of success with STT. I have the 2000c7 project-X and it is a no go for 32m

well I figured, my 2200c8 are the same as well, on all the boards I tested.
04-13-2011, 10:23 AM
quake6

Quote:

Originally Posted by l0ud_sil3nc3

really so you just need the dank, no schwiggity schwoo, I bet GTX2's would do great then.

I have a set of STT 2000c7 that I am trying to sell and they are new, is it worth keeping them and trying them out?

Not really, I have GTX2 and I hardly run it on 2133MHz for Spi 32m. 7-7-7/8-8-8 above 2160 is really hard
04-13-2011, 11:22 AM
Splave

Quote:

Originally Posted by LardArse

Here is a double edged sword, tip for maximizing bclk/yet the wrong setting can produce CPU sensitivities to '00' at resets etc :

http://g.imagehost.org/0393/skew.jpg

First set Skew driving voltage to 1.04v, set bclk skew to 0 , rest of skew to auto and start pushing bclk to find limit.
next set Skew driving voltage to 1.04v, set bclk skew to -8 , rest of skew to auto and start pushing bclk to find limit.
next set Skew driving voltage to 1.04v, set bclk skew to -12 , rest of skew to auto and start pushing bclk to find limit.
if bclk is increasing going to -12 then slowly lower skew driving voltage from 1.04v to try to max bclk again.

for reducing bclk First set bclk skew to 0 , set Skew driving voltage to 1.04v,rest of skew to auto and start rewducing bclk to find limit.
next set bclk skew to +12 , set Skew driving voltage to 1.04v,rest of skew to auto and start rewducing bclk to find limit.
if bclk is redusing going to +12 then slowly increase skew driving voltage from 1.04v to try to reduce bclk again.

Thanks was stuck failing to boot at 107, set -8 and 1.04 and now 32m running at 107.2 :)
04-13-2011, 11:50 AM
cstkl1

well i am stuck at 106.7
i clock every 25mhz on dram

been trying for 107.8/107.9 to get 2300mhz

hmm the i/o skews seems to change when i change dmi A/B skews.

and the rtl thingy seems cant run anymore other than 14.
04-13-2011, 02:36 PM
owikh84

Quote:

Originally Posted by seba84_2005

I make wallpapers ;) how do you like?

Nice seba! :up:

Quote:

Originally Posted by l0ud_sil3nc3

well I figured, my 2200c8 are the same as well, on all the boards I tested.

My AData 2200C8 is best at 2133 7-8-7 only, at an insane high vdimm 1.825v. 7-7-7 is no go.
DomGT 2000C7 works like charm at 2133 7-7-7 @ 1.72v
04-13-2011, 02:39 PM
kpablo

So... 16x/16x with NF200 has better performance than native 8x/8x???
04-13-2011, 07:50 PM
sfxs

Very nice seba :up:. Are you taking any requests on the wallpaper?

Personally I'd like one in 1920x1200 with just the RoG logo in the middle and not the board on the lower right. 2560x1440 and 2560x1600 would be nice for future-proofing as well.

-sf
04-14-2011, 12:23 AM
Lu(ky

Quote:

Originally Posted by sfxs

Very nice seba :up:. Are you taking any requests on the wallpaper?

Personally I'd like one in 1920x1200 with just the RoG logo in the middle and not the board on the lower right. 2560x1440 and 2560x1600 would be nice for future-proofing as well.

-sf

+1 2560x1600 :up:
04-14-2011, 04:25 AM
seba84_2005

There You go ;)

1920x1200 RoG logo only in the middle:
http://img831.imageshack.us/img831/5...inglero.th.jpg

2560x1600 RoG logo only in the middle:
http://img191.imageshack.us/img191/3...inglero.th.jpg

1920x1200 fixed.
04-14-2011, 05:08 AM
sfxs

Very nice again; (edit: thanks for the quick fix).

-sf
04-14-2011, 08:00 AM
jcniest5

Quote:

Originally Posted by seba84_2005

There You go ;)

1920x1200 RoG logo only in the middle:
http://img831.imageshack.us/img831/5...inglero.th.jpg

2560x1600 RoG logo only in the middle:
http://img191.imageshack.us/img191/3...inglero.th.jpg

1920x1200 fixed.

Hey, make a 1920x1080 also, since that's the native resolution of most 1080 LCD/LED monitors these days.
04-14-2011, 09:07 AM
seba84_2005

No problem :up:

http://img222.imageshack.us/img222/3...4200519.th.jpg

http://img52.imageshack.us/img52/554...inglero.th.jpg
04-14-2011, 09:13 AM
jcniest5

So you gonna allow people to download it/them and use as wallpaper, is that your plan?
04-15-2011, 02:45 AM
aoch88

Has anyone tried the latest/new BIOS? :) How is it compared to the recent 1101?
04-15-2011, 02:46 AM
Alex-Ro

1303 best so far :)
04-15-2011, 02:51 AM
angkies

my luck.. i buy P8P67 Deluxe B3 last week and i can run my Hyper 2133 7-8-7 @ 1.725v n 2133 8-8-8 @1.6v (24/7), this is my 2nd board that can run my hyper go to 2133, my first board was UD7 that can too... other board like P67 pro, Giga UD4 or Asrock Fatality failed to run my Hyper to 2133 :(

+1 for Asus P67 Deluxe B3 :up:

http://img861.imageshack.us/img861/6154/corsair.jpg

http://img638.imageshack.us/img638/3853/55ghz2133c7.jpg
04-15-2011, 06:31 AM
The Asgard

1485 is out

http://www.kingpincooling.com/forum/...t=1041&page=14

Changed some memory stuff
added Memory timings:
I/O Latency + RTL Offset

can play with it with oc memory...
04-15-2011, 07:57 AM
fab-45

Hi

i show 1.38V CPU for 5000Mhz

but me have 1.45V CPu for 5000Mhz

how do that on maximus 4 ex ?

the P8P67 deluxe is better than maximus 4 ex ?

i have number on CPU : L101B540

Thanks ;)
04-17-2011, 01:13 AM
clone38

Sorry for this being off topic but i have this board and a MM 10 slot pci case and would like to fit 2 Asus GeForce GTX 570 DirectCU II to run in sli recon they would fit ok?
04-17-2011, 06:44 AM
Splave

they will fit but 1 will be in a x8 slot I believe
04-17-2011, 07:19 AM
owikh84

2x NF200 pcie will run SLI at x16/x16.
04-17-2011, 07:48 AM
clone38

Both 470s are double slot and have a nice gap between card`s but the 2 slot card`s will be to close i think and will maybe overheat them.
04-17-2011, 11:34 AM
fab-45

Hi

i have a question for a choise (memory) on M4E

the best kit 2x4Go ?

corsair DOMINATOR GT pc 16000 cas 8 9 8 24
or
[ Ripjaws-X ] F3-17600CL7D-4GBXHD cas 7 10 7 27

thanks
04-19-2011, 11:05 PM
gjeewaytee

What software do you guys recommend to stress-test the cpu?. I have been using Prime95 for ages now and want to use something else. Maybe something new "on the marked"...I feel that running small fft is just overkill and not beeing nice to me at all :D
Or is it still Prime95 wich is the main test software?

Show 100 post(s) from this thread on one page

All times are GMT -8. The time now is 04:42 PM.

XtremeSystems
