Volt Mod Guru (Mallet) has his Asrock 775Dual-VSTA board at 318FSB
For the full story.
http://forums.vr-zone.com/showthread.php?t=93127
Also some overclocking hints for the 775dual-vsta. In the Bios set:
Cpu:pci-e async
Pci-e 117mhz
spread spectrum - Disabled
V-link - normal
;)
Woot, not a single reply!? :mad:
Well here's a :up: from me.
Now I can improve on my '01 score : http://service.futuremark.com/compare?2k1=9053652
But I don't want to kill this mobo the first week. :slapass:
Some people don’t like challenging boards. :wierd:
324FSB so far for this motherboard is excellent.
I'd die for 324 FSB ( @ stable ), what's the secret? :p:Quote:
Originally Posted by Alchemist
I think IDE Controller in the chipset is my problem, should I do a Vchipset mod? What do You think? I'm stuck on 300 FSB.
( maybe I should get a second Asrock 775Dual-VSTA board, hey they're so cheap )
:)
Have you read these threads?
Your answers should be here, if not I will try to answer them.
http://forums.vr-zone.com/showthread.php?t=90194
http://forums.vr-zone.com/showthread.php?t=89038
http://forums.vr-zone.com/showthread.php?p=2271196
http://forums.vr-zone.com/showthread.php?p=2271196
:p:
Nice thanks
Alright, finally able to log in.
I've now done 2 of the Vmods; Vdimm & Vnb.
350 FSB @ DDR400 @ 2 2 2 5 1T speed!!!
:D :D :D
Sadly I'm only j/k of course, but the mods works and I'm now able to clock the BH-5 mem up to 225MHz mem speed ( 2.95V needed ).
Only bench stable though.
But my BH-5 sticks aren't interesting for 24/7 use, the 2GB DDR UCCC mem are and I have one hell of a tough time to clock them at DDR400 @ 1T settings. :(
I'm now going to reboot and see if I can break 302 FSB barrier with the Vnb mod in place, wish me good luck! :cool:
Edit: @Alchemist; yeah I've read those threads. If I can't get 300 FSB 100% stable ( which I apparently can't when Prime95 fails ) I'll put CPU back to default and don't bother clocking this setup at all.
Good Luck and don’t give up I'm sure that you like many others will find more FSB eventually.
These are the heaviest thread out there on 775dual-vsta.
http://forums.anandtech.com/messagev...&enterthread=y
http://forums.anandtech.com/messagev...&enterthread=y
:toast:
Alright, thanks! ;)Quote:
Originally Posted by Alchemist
I'm now dual priming at FSB300, with 2GB DDR UCCC mem at DDR400 @ 3 4 4 10 1T @ Vdimm=high.
So far so good ( currently at 40 min :woot: ), the thing is I need to cool these mem with very cold air, with low ambient temp ( +5'C ) or else Prime95 craps out after 4 minutes.
That - or - maybe my Conroe E6600 is utter crap and needs the very low ambient temp for 2.7GHz.
It can't be that bad, can it? :eek:
I've removed all Vmods because they didn't help me a bit ( apart from the Vdimm mod which helped me clock BH-5 mem a lot higher ), but the low temp definitely do so I'll keep the balcony door open forever and put on more clothes. :stick:
No actually, I'll remove the heatspreders on the mem. Get some Cu ones, use a good thermal paste and add a fan over the sticks.
They must be overheating.
I'll work on higher FSB when I can get this 100% stable.
49 minutes now! :D
55 minutes now! :D
1 hour now!!!!!!! :D
Edit: sh:banana:t!!!!
Dual priming at 306 FSB, doomed to fail! :D
I actually made a misstake earlier, I used fast V-link speed. :slap:
Adjusted some settings and said: "If FSB300 doesn't work, maybe FSB306 will". You know that "famous" FSB300 bug. :D
18 minutes now! :slobber:
It's good to see that it’s hanging in there for you at 306FSB. :toast:
How much power are you injecting into your ram? :CTF:
It’s the first time that I hear someone with this mobo running on sizzling ram. :smoke:
:caution:
He He, 40 minutes then a big :explode:.
Core 1 always fails.
I'm only using 2.7 Vdimm = high in BIOS. These mem only need 2.6V to function properly up to 260-270MHz. They're PC4000 mem.
But I can dual prime - as it seems - Small Test @ FSB306 forever so I guess it's not the CPU, not the mobo but memory or northbridge.
Fine, let's put mem on divider or use 2T or use the flex "poor perf" option You may say!?
The sad part, it doesn't help me. Large test still errors out at 300 FSB. :slapass:
I must play more with advanced timings.
But first I'm going to try boot at FSB312 and do some torture with dual prime Small Test. Test the CPU so to say. :cool:
Sounds like a good idea. :cool:
Huh, 312FSB didn't post, how odd!??! :banana:
Starting all over with different mem, this time with 2x256MB PC2700 mem @ 3/5 divider.
IF IT FAILS NOW at FSB302 in Prime95 Large Test it's not the mem :confused: and ... I GIVE UP!!! :mad:
Thanks for the support! :toast:
It failed after 2 minutes ... Good Night! :cow:
FSB315!
:fact: :fact: :fact:
Wow That’s impressive what did you do to get that? :sonic:
:eek2:
Alright, when I'm using a X1900XT I've never bothered to do the Vagp mod.
How could an AGP mod possibly help me pass memtest & Prime95 large test at FSB300!?? :stick:
Well, I did the mod and immediately I could pass memtest86 not only at 300FSB but 310FSB too, and post & boot at FSB315!!! :D
So I guess this is in reality a memory controller mod ( or somehow connected to mem ), kind of.
Still, dual Priming large test fails at FSB300 even though it's perfectly benchable up to at least 315FSB. :confused: :rolleyes:
AGP volt mod helping the FSB reach higher while you running a PCI-e card? :hehe:
That's strange but it seems to work for everyone that’s tried it so far. :up:
I have done the highest cpu pin volt mod for the D 805 and got it to
4000Mhz.
I can boot into Windows at 4080Mhz but its not stable.
Thats 50% Overclock with this mobo happy happy!
http://img135.imageshack.us/img135/3...erclockst6.png
:banana:
WOW, great OC! :woot:
Is that Prime stable?
Maybe we should swap hardware, You take my stuff and I take yours?! :slobber:
No luck for me, no FSB300 for me. I even lost the damn MAC address after a CMOS reset. "MAC address invalid in both Flash and CMOS, press F1 to continue"!!! :D
So, no 10/100 MBit LAN until I figured out how to recover the address, my network card.
The chip had to be reprogrammed.
http://www.asrock.com/support/QA/TSD...0and%20CMOS%22
So, we're the only 2 ones with an Asrock 775Dual-VSTA mobo!?
I guess we are. :cool:
I have not run prime but it works all day long with all apps and games so far. :D
Sorry to hear that your system has crashed big time. :(
Yeah, sorry to hear that your system crashed. It happens though :\.
Um I think the losing of the MAC address was a BIOS issue. I believe to get it fixed would require sending the board back to asrock. You could always use this as an excuse to upgrade to gigabit ethernet card :D
Yeah, losing the MAC address is probably a BIOS issue.
And not a small one either. But it can be fixed and I luckily recovered it. :p:
How to Write MAC address of your motherboard;
http://www.asrock.com/support/Download/MAC_tool_dl.htm
1. Create a bootable system floppy disk.
2. Download MM.zip and unzip MA, MAC.EXE, and MM.BAT to the floppy disk.
3. Use notepad to open MA file in the Windows OS.
4. Find the MAC address sticker on the motherboard and replace the MAC address in the MA file.
5. Boot the system from the floppy disk, run MM (A:\mm <Enter>) to write the MAC address.
6. To read the MAC address from the motherboard, run A:\mac r<Enter>
It works!
Great mods Mallet! :hrhr:
What's the Vnb mod good for, seems to do nothing for stability & OC ( in my system )!? :)
I'm about to order a second Asrock 775Dual-VSTA board. :ROTF:
That's great to know that the mac address problem can be fixed.
Yeah the northbridge voltage doesn't seem to help anyone's oc, I just posted it cause someone was asking for it. the one I labelled as Vagp, going from 1.59 to 1.79v, was good for about 15mhz on the fsb for me. setting the PCI-e to 117mhz was huge also.
Alchemist/Mr Vain, thanks for posting this on here and anand, I forgot my password on that site and i dont know what email i signed up with lol.
Sign up with another name; :idea: it would be a shame not to continue to contribute to the vr forum thread that you started. :comp10:
:)
oh no my anandtech account is the one im locked out of, my bad i made that sound confusing.
Alright, I made a long reply to this post earlier but my system crashed ( in OC mode of course :nono: ) when I was about to "Submit Reply"! :(Quote:
Originally Posted by Mallet
I'll keep it short this time, for safety reason. :D
Does it have to be exactly PCIe 117MHz, I mean 120MHz should work too, right?! :)
Now it seems like the Vnb mod isn't useless for me, seems to help in dual Prime and dual Super PI 32M.
This is what I currently use;
PCIe = 120MHz
PCI = 33.33MHz
Vcore = ~1.26V ( E6600 / on the box can be read 1.35V max ?? )
Vagp = ~1.70V
Vnb = ~1.43V
Vdimm = ~2.75V
DDR400 & CPC 1T settings & flex off.
Now things are dual prime stable up to FSB290 at 2.5 3 3 6 1T with 2x1GB DDR mem. :cool: :cool: ( Edit: not so cool really :( )
I wonder if Vnb helped because you are running command per clock at 1T.
Well - after further testing - I wonder if Vnb mod helps at all because dual prime always errors out after ~4 hours in OC mode.
Stock speed works, but that's not fun. :stick:
Hm I guess I could OC 5% ...
I can bench at FSB315[+] with the mods in place but ... I still can't get this Asrock 775Dual-VSTA board to OC 10% and maintain 100% stability , that's it!! Mem craps out. Maybe my mobo sample has a weak mem controller!? :(
DDR333 setting or flex option isn't for me but I guess I could try 2T.
----
http://www.komplett.se/img/p/400/323507.jpg
:slobber: :slobber: :slobber:
Most people have to run 2T with this board, even with good ram, and no OC. From benchmarks I've ran its a 2-3% performance hit, but its completely stable whereas 1T would would crash my games.
I use DDR 400 setting 3-3-3-8 2T. with fsb at 315.
http://img156.imageshack.us/img156/7...rimeyj3.th.jpg
Setup like this I'm scoring nearly 30k in 3dmark01se with a 6600gt.
The good news: CPC 2T definitely makes things more stable! :)
And the perf hit is small ( less than 5% ).
Yeah, I wish I could use 3 3 3 8 2T beyond FSB300 but my 2x1GB mem won't let me. Beyond FSB300 I need to use 3 4 4 10 2T and while this doesn't sound too bad there are times when 9x290 2.5 3 3 6 1T provides better performance than 9x310 3 4 4 10 2T, like in WinRAR 3.61 single- & multithreading hardware test and dual Super PI 32M. :woot:
3DMark01/03/05/06 are of course a bit faster with 9x310 3 4 4 10 2T settings.
I did try 9x310 2.5 3 3 6 1T @ DDR333 speed and it wasn't too bad, actually quite good but with DDR mem we're already short of mem bandwidth so I feel DDR400 speed is the way to go.
The bad news: :banana:
Edit: I mean the bad news: I got no clue how 1T will work in games on my setup, because I haven't gamed yet on this mobo. But it could be like You say, it'll crash!
right my friend has this board and a intel 805 he seems to be having problems booting past 160fsb which is strange because it will boot then blue screen the memory is fine he has ocz ddr2 667 so i think could be dodgey install of windows or could it be the ide controller ? if most cpu's opperate at 200fsb stock then why should this be having trouble
and this board does undervolt quiet bad
http://img155.imageshack.us/my.php?image=fdgdfko3.png
http://img176.imageshack.us/my.php?image=fghfdus5.png
there are screenys it just doesnt seem to make any sense
and the karl (l) aime that is me :P
Dude this CPU D 805 has a 20x Multiplier which makes it unusual.:eek:Quote:
Originally Posted by mitsirfishi
200fsb x 20 cpu multiplier will yield you 4 MHz overclock, that is possible on this mobo only with a CPU pin volt mod as I have done.:banana:
You should be able to achieve a maximum of 270fsb with stock voltage.:hehe:
Set IDE strength to medium or high on the bios and see if it holds.:scope:
A fresh Windows Install is a very good idea for this mobo from a lot of what I have read about it.:explode:
Try in the bios
Overclock Mode: Async
CPU: 165 to 170
PCI-E: 117
Spread Spectrum: Disabled
DRAM Frequency: auto
Flexibility Option: Enabled
DRAM Latencies: auto
DRAM Voltage: auto
AGP Voltage: auto
AGP Fastwrite: Enabled
AGP Aperture Size: 256Meg
V-Link Speed: Fast
IDE Drive Strength: High
Disabled Floppy, Game Port, MIDI port, etc. If you don’t use.
Hope your friend has a good PSU that helps heeps.
well he has the x-pro 460watt with dual rail 12v amps in total of 30a amps so its powerful enough
I see some praise for your efforts Mallet on that other place.Quote:
Originally Posted by Mallet
Oliver is getting 325FSB Stable!
I now believe that around 340 FSB (only 15 fsb more) with this mobo is not that impossible with a few more refinements.
Hi there,
first of all I would like to thank Mallet for the trouble and time, which he sacrificed, in order to make this Mod possible. :kissbutt:
You are a genius :bows:
With your Mod I could reach easily FSB 325 (with a few Bios attitudes).
And the best... it runs stable... :bravo:
I wait likewise for a pencil trick, :idea: in order to increase the DDRI tension.
Perhaps you would have time and desire for a further challenge...:hehe:
Thank you again,
Oliver
:)
Let us know how he goes with these bios tweaks’Quote:
Originally Posted by mitsirfishi
That Gigabyte board is a real good, but the price is not. :mad:Quote:
Originally Posted by OnLine
This board is interesting; with the right bios it could be a real gem! :gamer:
http://www.hardwarezone.com/articles/cat.php?id=6
:poke:
well we are going to try it tomorrow and see what luck we have :P
All the best with it.Quote:
Originally Posted by mitsirfishi
:D
online shame your ram isnt good enought to run 1:1 up to higher speeds because you get better memory bandwith running 1:1 rather than any other ratio even if your 200mhz slower for example
Well, DDR400 ( actually a 3:4 divider ) at 2.5 3 3 8 1T works nicely up to FSB285-290 but beyond this speed I need to lax something if I insist to use this divider. Beyond FSB300 I need to use 3 4 4 10 2T if I insist to use DDR400 and want this setup dual prime stable. :)Quote:
Originally Posted by mitsirfishi
CPC 1T instead of 2T counts for ~10 FSB's ( ~100MHz ).
2.5 3 3 8 instead of 3 4 4 10 counts for ~10 FSB's ( ~100MHz ).
Roughly speaking!
DDR333 mem speed ( the 3:5 divider ) is - like You say - pretty crap and flexibility option also provides poor performance ( maybe even worse!!? ).
Now, if I can keep this setup 100% stable at 9x285 with 2GB mem at DDR400 @ 2.5 3 3 8 1T I'm actually not too disappointed.
That's a 7% OC!!! :slobber: :D :eek: ;) :banana: :cool: :fact: :clap: :cheer: :woot:
Hey Online Mallet has hit 340FSB Unbelievable; he’s maxed out the bios FSB!! :yepp:
http://img149.imageshack.us/my.php?image=340vf1.jpg
:nuts:
Unbelievable!!! :shocked:
My sample, well she's is not too friendly and I've now lost my 7% OC!
Back to the drawing board or more likely back to stock speed.
This mobo hates me :( ... and I hate back. :mad:
right we managed to get a boot at 3.42 but wasnt stable at all itunes erroed with along every program we tried to open aswell as prime95 had errors so had no luck with my friend :(
Dude you have reached the MAX that this CPU will achieve in this board with stock voltage.Quote:
Originally Posted by mitsirfishi
There is nothing wrong with the mobo that I can see, mine reached exactly the same value before I dropped it back to 3400 and then back to 3380 for very good stability.
Any further overclocking from here means a CPU pin volt mod.
If that’s the way you want to go then, you’re going to need water cooling or something special for cooling.
If you want a pin mod guide, let me know.
:toast:
i dont think that the cpu has hit its limits when im at my friends house again im going to try his cpu in my board and ill let him use my 920 to see what fsb the board will achive then we both got arctic frezzers and im running at 4ghz atm running 1:1 on my asus board reaching 55c load so not that bad eh :)
yes i would like to see the cpu pin mod :D does it work on all lga 775 cpu's varying from 5xx-9xx series ?
This CPU in this board with the low voltage it provides, has reached its maximum but give it more voltage and it will go to 4 GHz +.Quote:
Originally Posted by mitsirfishi
The problem here is the boards low voltage power supply and lack of extra voltage supply features in the bios.
Yes the CPU can go higher if you give it more voltage hence the pin volt mod.
Guide
http://sg.vr-zone.com/?i=3931
Dicussion
http://forums.vr-zone.com/showthread.php?t=89038
:coffee:
This new setting is a magic bullet for extra memory bandwidth according to everyone that’s used it! :YIPPIE:Quote:
Originally Posted by OnLine
In the Bios find
Advanced Host Conf:
Pipeline DRQCTL - Enabled It
Thanks to Oliver for finding this out. :toast:
Try it and you should be Amazed, it’s a huge boost. :woot:
In the 1.8 & 1.9 bios it's under the chipset section 2 below the memory command rate option
Do a memory bandwith test first with it disable and then enable it.
You wont be dissapointed :smileysex
ENJOY :hump:
:D
That's a nice boost, a huge boost!
4800MB/s -> 5900MB/s. :cool:
Thanx Alchemist! :toast:
Actually, I were at AnandTech Forums @ http://forums.anandtech.com/messagev...&enterthread=y and read about this one ~8 hours before I read it here. I even started a thread @ FM about it but the kids aren't interested.
Alchemist = Mr Vain though, so my thanx stands.
While synthetic memory read bandwidth tests shows a 20-25% boost, real world is more like 0-3% ( but it actually makes a difference ).
Dual Super PI 32M is a memory intensive app.
Pipeline DRQCTL = AUTO;
http://img245.imageshack.us/img245/1...3361tasnm0.jpg
Pipeline DRQCTL = ENABLED;
http://img150.imageshack.us/img150/1...3361tbsxt4.jpg
:)
1Vain + 1Alchemist=1 :D :D :D :D :D :D
Done! :D
http://img246.imageshack.us/img246/8...01846reiq9.jpg
http://service.futuremark.com/compare?2k1=9072982
Now time for a real Conroe mobo. Or maybe that could wait a month or two?!? :confused:
Thanx to Alchemist for making this possible, posting the mods! :slap:
EDIT: and of course thanks to Mallet, the creator of the mods! :slap:
322FSB Wow great score (massive score) :slobber: for this little board with a Via chipset.
:toast:
:D
:toast:
Yeah, a $60 mobo with DDR+DDRII MEM support and AGP+PCIe VC support and 50K in '01. Who can complain?! :woot:
But ...
FSB 400 sounds so tempting I don't know if I can resist getting a P965/I975X mobo. I can't afford 2x1GB DDRII mem right now but before this year ends I'll get some new stuff.
Mobo, mem, G80, LCD Monitor, VISTA ... *sigh*
I must make smart decisions now! :hm:
What board are you looking at?
Is it going to be a Kentsfield compatible board?
:)
newegg had some open box ones for $27.00 shipped, I ordered 2, just to hopefully insure atleast one works.
got the $172.00 e6300 from Hardwarerebuild,and have lots of different ddr ram to use, sold my opty 165 motherboard and cpu for $50.00 more than this cpu/motherboard cost, so even at stock i will be happy.
all the info here will help alot, i will def do some volt mods, that is if both boards work from the get go.
give me 3 or 4 days and i will be posting my clocks with my 7900GTO PCI-E, or 6800GT AGP.
does the 4x pci-E limit the card any???
also i have a 1gb stick of pc2700 kingston that does pc3200 easily, but only the one 1gb stick, how badly does single channel hurt performance, will probably just use my 2 x 512mb BH-5 Hyper-x good for 220 cas2,2,2,5,1T on other boards at 2.7V.
any more advice would be apprciated.
will be useing a antec true 550watt eps so power should no be a problem.
@Alchemist;
I'll probably get the Gigabyte GA-965P-DS4 ( Intel ICH8R ) and while this board does support Kentsfield I don't really care. A $1000 4 core Kentsfield is far too expensive for my needs, I must fill the 2 cores first.
:p:
------------
@tbogstad;
PCie x4 cuts performance by 0-10% depending on app/test, usually the hit is under 5%. Vertex shader takes a larger hit than pixel shader.
HDR takes a hit. The hit is reasonable.
http://img410.imageshack.us/img410/8855/fear2ly7.gif
http://img336.imageshack.us/img336/7581/q42uk7.gif
That's with a 7900GTX OC.
This mobo is a love-hate affair, but it's a cool mobo.
I'd suggest; definitely use dual-channel. I've tested single-channel and depending on app it's ~2-10% slower than dual-channel.
Multitasking benefits from dual-channel ( needs mem bandwidth ).
Yes I've tried 2x512MB BH-5 mem on the mobo, and it rocks but a Vdimm mod is needed. This mobo eats Vdimm, 2.7V stable on an other mobo means 2.8-2.9V stable on this one.
Expect an OC of FSB 285-295 ( Orthos stable ) out of the box. Well even better, expect nothing then You won't be disappointed with the board.
:)
That board has been getting some good reviews.
I won’t be looking for awhile this 775dual-vsta will do me till the Kentsfield boards are out and established.
:D
Great find. I should probubly upgrade some time :\
The VSTA or the Gigabyte?Quote:
Originally Posted by Bbq
:confused:
could somebody give me a pic of the L6714 ic(that mallet on vrzone said he has done) that u can do the vcore mod. show the points to connect and wut trimmer. i have a 50k ohms witch should work fine but need to no were to soldier to. any help would be great thanks
Hey NatedogQuote:
Originally Posted by natedog420
Why don’t you visit him and ask about that picture or more info?
Guy's using his mods are getting 340FSB.
He uses this thread below. You can ask him and get a quick reply.
Go to the last pages if you looking for the more recent stuff.
http://forums.vr-zone.com/showthread.php?p=2438965
There are some similar chips on this mobo to the vsta maybe your answer is here also.
http://www.xtremesystems.org/forums/...ad.php?t=95250
:D
NEW BIOS 2.10
Some reckon that they are getting 200 points more on the Sandra Memory Bandwidth test with this new bios.:slobber:
http://www.asrock.com/support/downlo...Dual-VSTA#bios
:)
Anybody running a Pentium D 805 in this board without blowing
the mosfets ?
a friend had his P-D 805 running at 166fsb (3.33GHz) for some time without any problems, but switched to a core 2 last week.Quote:
Originally Posted by Digz
Thanks
I'd be happy with (3.33GHz) until i get a conroe
anybody have some vcore Mod for this board ??
Quote:
Originally Posted by Digz
I have done the highest cpu pin volt mod for the D 805 and got it to
4000Mhz.
I can boot into Windows at 4080Mhz but its not stable.
Thats 50% Overclock with this mobo happy happy!
http://img135.imageshack.us/img135/3...erclockst6.png
:banana:
I have been running it for months now at 3960Mhz and 3900Mhz without a single problem.
Get plenty of air to the VRM'S.
I'm using cpu water cooling.
I could run my D 805 on stock voltage up to 3360Mhz stable and boot into windows at 3420Mhz.
:D
short question
what's the max vcore @ Asrock 775Dual-VSTA Volt Mods
1,5 V oder 1,6 V ?????
I'm using this pin volt mod guide for vcore as it easy and works great.Quote:
Originally Posted by OCPerformance
http://sg.vr-zone.com/?i=3931
Good help in doing the pin volt mods here.
http://sg.vr-zone.com/?i=3931
:)
1.6VQuote:
Originally Posted by OCPerformance
:gamer:
Thanks ;)
@Alchemist
Thanks for the feedback on the D 805 :)
I accidently went into this thread and was amazed by the goldmine I found here!
I am running a P-D 805 and the vmid for it looks promising!
I'm using Gigabyte GA-8I945P-G-RH motherboard. I am able to change vcore in this board(unlike your board), up to 1.6v. The problem is that this motherboard has a serious vdroop and therefore my real vcore is only about 1.4-1.52when setting 1.6v.
If I use this volt mod for the processor at max voltage(1.6v) will I still be getting this vdroop? or will I infact get 1.6v or very close to it?
I think that's what preventing me from getting 4Ghz stable with the 805. I'm currently able to boot with 190FSB stable, and use Easytunes/Clockgen to get the extra 10FSB to achieve 4GHz(which isn't very stable either). Can't directly boot with 200FSB though.
I would truly appreciate your help guys!
EDIT: temps are great btw...48c full prime95 load, 27c idle.
All I can say is that you can try the 1.6 Pin Volt mod and if it does not improve your volt stability issues, just scrap off the silver varnish (with a knife or needle) and your back to where you were before.Quote:
Originally Posted by GGuyZ
You must follow the guide and find your cpu default voltage.
;)
2.20 bios is out now i like it better than others
Any vcore mods? NOT THE PIN MOD, I tried that mod and it didn't work, one core is disabled after that mod. I'm looking for a mod for the motherboard to increase the vcore. Thanks.
I would like to know if there is a vdimm mod that consist in connecting the 3,3V line of the PSU directly to the RAM with only a wire.
I've done this mod before on other motherboards but I don't know if it will work on the ASrock 775DUAL VSTA.
Sorry for my english :slapass:
It seems like this board can hit 325-335fsb with all the mods. I'm about to order a E6600 for this board, just a few questions. How do I measure the resistence after shading the Vnb and Vagp resisters? Do I touch one lead (from the multi-meter) to the resister the other to the case or one lead to each "leg" of the resister? Does the power needs to be on to check it? Also, did anyone tried Verdeva's pencil vdimm mod? Cuz I don't want to solder if possible.
It seems like Oliver2000 over at VR Zone is having the most success with this board, did anyone else duplicated his settings? (Plus PCI-E 120, AGP 1.94, and NB 1.58) Did you get the same results? If so, what resistence did you use to get to those voltage (for AGP and NB)? Sorry for all the questions, I don't want to fry my mobo when I start modding. Thanks.
@Alchemist
Are both of your cores running the same as before the pin mod ?
and have you had the 805 underload for long lengths of time as
i'm concerned about the mosfet/volt regs overheating.
well i've had the 805d/775dualvsta combo for about two months now. With stock Vcore I only got the cpu up to 3140...kinda weak, but I ran it hard for two months and had no problems. After putting off my pin volt mod for too long, I broke out my conductive ink and electrical tape today, very exciting. Unfortunately that wore off quickly as I'm only able to get a 163 FSB overclock (3260) with the 1.5volt mod!!! Absolutely Ridiculous! Bios, & CPU-Z show 1.48-1.5 volts consistently so I know my mod was done correctly (not that I needed that to tell me, I tested my connection with a multimeter and it's nowhere close to touching another pin landing). This absolutely infuriates me and I'm about to piss my wife off and buy a conroe. Any ideas? Alchemist I'll call you out, I've seen you're results here and on other forums as well with this combo!
775dual-vsta
p4 d805
1gb ddrII-667 3-3-3-9
80gb WD IDE
Temps on par
What are the regular Voltage options in BIOS?
I remmebr it being low med and high I think... what are the values?
if u knew more about the board u would no theres no vcore adjustments only agp and ddr. no to be rude or anything. i got my p4 511 2.8ghz on stock volts to bench at 3.9ghz so i think its pretty good. i will try volt mod when my board gets here. first time i had a 1.6 bios chip with a 880 pro/ultra chipset and could hit 3.8ghz benching, it burnt up cuz of stupidity by me lol so i rma it back to newegg. got 2nd board and it came with 1.7 bios chip and a 880 pro chipset and i could bench at 3.9ghz, but the agp slot burnt out of this one dont have a clue y i could run orthos on ram and cpu as long as i wanted with no problems. as soon as i did sumthing 3d related or anything thats using the videocard it locks up so agp slot is defective cuz i tried 2 cards that work great in my other computer. so it went off to newegg today and gonna be waitin for a new one again and i hope its the last time. o ya 3.9ghz with my cpu is 186 fsb and was stable as can be.
When I did the last pin mod fromto1.5 to 1.6volts, the VRM's and mosfets became very warm and there was a burn smell for awhile, but I kept good ventilation around those areas and have had no problems. You may want to consider a dedicated case fan for this area.Quote:
Originally Posted by Digz
The mosfets legs and the VRM’s legs did become browner from the extra heating initially but since that first situation it all has settled down.
I did all the mods accept the 1.55 volt mod, this gradual burn in perhaps helped the board.
I would not recommend a volt mod from stock to 1.6volts straight away, gradual volt modding is probably safer due to the gradual burn-in process.
Both cores are functional.
I play games for hours with a pc load of 50 t0 60% and CPU gets up to 74° with water cooling.
You will need water cooling to run at above 3800MHz in my opinion.
:)
Thanks for the info :)
I can only put it down to maybe a different CPU stepping.Quote:
Originally Posted by mcnannay
I and quite a few others can get the D 805 CPU to boot into windows at
3400+ and run stable at 3360 or 3380 on stock voltage.
I have a 750W psu maybe that’s keeping the voltage more stable, but honestly if your ram is set loose in the bios and other bios settings are correct then I have no answers.
Sorry to hear that.
:(
Quote:
Originally Posted by FLMJIGGY
There are no motherboard cpu voltage adjustment only via mods.
I run the board at 300fsb (E66@2,7ghz) 24/7, its 100% bench stable at 325fsb (2925mhz), fsb 326 wont boot.
Whit a almost std AGP x800xtpe (can do about 670/660 whit pencil mod):
43k in 01
http://service.futuremark.com/compare?2k1=9086123
17k in 03
http://service.futuremark.com/compare?2k3=5001223
7.9k in 05
http://service.futuremark.com/compare?3dm05=2262336
2.7k in 06
http://service.futuremark.com/compare?3dm06=553053
No mods done, yet, and went from 285fsb to 300fsb stable whit bios 2.10 from 1.90 whit DDR2 at 1:1 -same result whit bios 2.20.
bios 1.90 and DDR1 was stable at fsb 300, so the chipset dont like the higher mem freq.
Good results dude!Quote:
Originally Posted by noxon
:D
ASRock 4CoreDual-VSTA
Is this truly a new model or just a box name change for the 775Dual-VSTA?
ASRock 4CoreDual-VSTA
http://www.ocworkbench.com/2006/asro...al-vsta/g1.htm
http://www.asrock.com/product/4CoreDual-VSTA.cn.htm
:slobber: :slobber: :slobber: :slobber:
That sucks
As i have only just bought my board and i have not fitted it yet
and a new version is out.
4CoreDual-VSTA & 775Dual-VSTA difference.Quote:
Originally Posted by Digz
This below quote is from a someone with inside connections to Asrock.
The main difference is that the 775Dual-vsta uses Pt880pro which is not suppose to run 1066FSB processors. 775Dual-vsta can run that is due to overclocking.
The 4CoreDual-VSTA uses the newer PT880Ultra which is certified to support the 1066FSB processor.
You can check http://www.via.com.tw/en/products/chipsets/#
To see the difference between PT880Pro and PT880Ultra.
:slobber:
Isn't the QX6700(B3) Kentsfield a quad core chip ?
http://www.asrock.com/support/CPU_Su...l=775Dual-VSTA
two thirds of the way down since bios 210.
Yes it is a quad core and your right the dual vsta does supports it but this new board might have a better overclocking north bridge.Quote:
Originally Posted by Digz
;)
I see
thanks
I don't think that there will be an ASRock 4CoreDual-VSTA board for a few moths outside china.
I can't wait for a complete review on it.
;)
Would be nice if i could at least get a few months out of the dual board.
:)
Hello, I'm searching for a vcore voltage mod, to overclock more my Pentium D 930. At full load the Asrock only gives 1,2V to the processor, where the nominal voltage is 1,3V.
I would appreciate any kind of help. Sorry for my bad level of english.
I see that you have been looking for this mod for awhile at VR Zone, I don't know any motherboard CPU volt mod for this mobo.
Sorry.
:shrug:
