Can't stable "Elpida Hyper" With i7-2600K

Quote:

---

Originally Posted by andressergio

my board seems to like my Stalents hypers 2200CL8

---

tested one of my supertalent elpida hyper 2200c8 kits and while it did 2133mhz 8-8-8-24 it needed 2T to run at 1.66v and couldn't run 1T like my Corsair Dominator GT 2000C7 :)

As explained here, after remounting Corsair H50-1 with proper mount and thermal paste contact, I managed to a bit more stability when it comes to all core benchmarking i.e. wprime 1024M at 5.2Ghz 1.490v bios (1.512v idle while ET6 reports 1.50v) windows was passable. But stil this Core i7 2600K L038A660 is hitting a ceiling at 5202Mhz on Gigabyte P67A-UD7 F8x bios.

5215Mhz was max validation and benchmarks below at 5202Mhz 1.512v idle.

5215Mhz 1.512v idle
4GB Corsair Dominator GT 2000C7
@2139Mhz 7-7-7-24 1.74v

http://fileshosts.com/intel2011/giga...cpuz_valid.png


5202Mhz 1.512v idle
4GB Corsair Dominator GT 2000C7
@2134Mhz 7-7-7-24 1.74v

Super Pi 32M
http://fileshosts.com/intel2011/giga...4s234ms_tn.png

Aida64
http://fileshosts.com/intel2011/giga...io2/aida64.png

MaxMem
http://fileshosts.com/intel2011/giga...io2/maxmem.png

Hexus Pifast
http://fileshosts.com/intel2011/giga...io2/pifast.png

WPrime v1.55 32M & 1024M
http://fileshosts.com/intel2011/giga...687_147375.png

Quote:

---

Originally Posted by eva2000

tested one of my supertalent elpida hyper 2200c8 kits and while it did 2133mhz 8-8-8-24 it needed 2T to run at 1.66v and couldn't run 1T like my Corsair Dominator GT 2000C7 :)

---

Looking good eva, hey out of curiosity have you tried flashing corsair SPD to the STT's?

VTT: 1.18 - Going higher on VTT = no boot
VDIMM 1.64v (tried up to 1.8v)
2T 8-8-8-24

No 2133, on UD3P.... I have Corsair Dominator GTX2.... And they need sub 1.7v for 2133 7-7-7-21 1T

Quote:

---

Originally Posted by chew*

Looking good eva, hey out of curiosity have you tried flashing corsair SPD to the STT's?

---

Nah haven't, i still need the 2200c8 for x58 so not messing with that spd wise :)

here's run on 2139mhz 8-8-8-24 2t

http://fileshosts.com/intel2011/giga..._trfc88_2t.png

Quote:

---

Originally Posted by M.Beier

VTT: 1.18 - Going higher on VTT = no boot
VDIMM 1.64v (tried up to 1.8v)
2T 8-8-8-24

No 2133, on UD3P.... I have Corsair Dominator GTX2.... And they need sub 1.7v for 2133 7-7-7-21 1T

---

yeah my 2600k doesn't like >1.18 vtt either. What does aida64 chipset sub timings look like ?

Messing with my Corsair cas 8 sticks not bad aida64 results blck was at 107-2 though

http://i274.photobucket.com/albums/j...0MHzmemory.jpg

Have not checked that, will do so this evening, however, I think this is quite odd.

Quote:

---

Originally Posted by chew*

Looking good eva, hey out of curiosity have you tried flashing corsair SPD to the STT's?

---

What program are you using to flash the spd? I can't get the 2200 C8 STT's to boot at all on P67.

SPDTool i think can flash ddr3 just not read the values ??

Starting to test 2x2GB Corsair Dominator GT 2000C7 Elpida Hyper's max mem frequency for Super Pi 32M. Let's start with loose 8-8-8-24 1T timings at max 1.74v vdimm.

http://fileshosts.com/intel2011/giga...32m_5_9033.png

http://fileshosts.com/intel2011/giga...p5_9033_tn.png

I did a backread but didn't find anything definite on this question: can the asus maximus 1v extreme run hypers (GT second gen 2000c7) at 2133 7-7-6 same as the gigabyte ud7? I have a couple of sets that I know run fine on a ud7 with 2133, 7-7-6 with 1.74-ish vmem but doesn't run SPI32M at all on an asus p8p67 pro at 2133 with tighter than 9-10-9 very high trfc even with high voltage:down:.

am thinking of getting the max iv e instead of the giga on account of the pcie lane assignment (for 2 VCs, an 8x lsi 9260-8i raid card, and maybe a soundcard) but this thing with the hypers might make me go ud7 with an x1 extender instead.

its been awhile alex ...2009 since you last posted :D

can't wait for your sb sp32m tweaked runs :D

this is my old MNH-e Hyper on UD7, this mem only can run like this on UD7.. i have try on asus n other mobo cant do 2133 8-8-8 or 7-7-7 :(

http://img96.imageshack.us/img96/9050/42754857.jpg

http://img40.imageshack.us/img40/5600/55143211.jpg


nice UD7 i really enjoy w/ this board :D

@angkies the maximus board doesnt run 2133 ??

Quote:

---

Originally Posted by Johnny87au

@angkies the maximus board doesnt run 2133 ??

---

i dont want buy Maximus bcoz its too expensive for me :(

Its a no go for me with 2133, just locks SPi 32M up between T1 & 3 every time. I've been right through the timings & voltages & nothing improves anything!!

Super Talent 2200 CL8

They run on the 1866 divider just fine between 1800 ~ 1834 @ 1.72 ~ 1.76v, havent tested 32M at 1866 but they do run/get into windows.

http://i106.photobucket.com/albums/m...830665201T.png

http://i106.photobucket.com/albums/m...834665201T.png
Might try flashing the Corsair SPD if I can find it.

@hondacity: yup long time. got the UD7 and it ran my hypers at 2133 776 just fine. however, the nf200 latency was dragging my LSI 9260-8i raid card. decided to get the asus MivE when the B3 came out as it had PCIE slots that bypass the NF200. Raid card runs fine and fortunately, it runs hypers at 2133 776 8GB as well (both 1103 default bios and latest 1204 official bios with CFG lock to disable).

http://i404.photobucket.com/albums/p...8GB_Hypers.jpg

wooo 5ghz and you're still top5 .... you definitely have sp32m mastered :D
