And also, isn't the pump pumping water INTO the res? Or am I misreading the picture? Seems like the tubing coming from the drive bays goes into the inlet, and then from pump to reservoir. That isn't optimal, and I just learned why (new thread in this section :P)
it goes...
res - pump (top inlet, side outlet) - res - CPU - GPU - res..
the outlet curls round an into the near side of the BIX2
Sorry, you posted after I started writing, I was referring to the guy before you (cl4w) :PQuote:
Originally Posted by Mankz_91
nope, his is going into his rad at the front.
Hell yeah! Christ illusion (><)Quote:
Originally Posted by Fameless
Few more pics is over here :Quote:
Originally Posted by septim
Lian Li PC65B+
I'm going to post up more pictures soon ... :)
Nice Rig FunkFlix!
@ FunkFlix, I don't like the rads and their location, but that is a matter of taste ;) Why not just use one 3*120mm rad?
The work you have made looks great :) And the inside is so nice and clean that it makes my little tidy up part of the brain cry for some of that in mine ;)
Thanks both! :toast:
I use the two radiators, because i had the one on the roof 2 years earlier, and i did not wanted to take it off, because of the holes and and that stuff. :)
very neat interior on your rig funkflix.
Final update on current setup :
New window: non UV reactive makes for a cleaner appearance imo.
Had a 'dabble' with some UV paint.
Gonna be upgrading to 1/2 tubing and WC the 7950GX2 next.
http://img.photobucket.com/albums/v6...UVpics1001.jpg
http://img.photobucket.com/albums/v6.../UVpics002.jpg
that looks :pimp: wat kind of tower is that? did you that panel?
Looks good Ic3man! :)
Too thin tubing though...
@ Bad213Boy. It's an Antec P180 with a custom made window.
he'll pimp it.Quote:
Originally Posted by Ic3man
is it me, or does your graphics cards look crooked a little?
ic3man i love your case.looks very awesome.
Cheers guys:D
Yeah I made the window (3 times in all until I got it right lol). It was a damn sight easier than cutting the holes for the triple rad though.
Its not the GX2 thats crooked its the XFI card. The inlet tube on the DDC is pushing it up slightly at the front end but in the photos it does look like the gx2 is wonky. As stated I'm going 1/2 when the spacer kit arrives so alot of stuff will have to be moved around so that will be sorted. I'll lose the SB waterblock (not needed except for bling purposes:D ) and I'm gonna try my hardest to mount the res somewhere internally...running out of space rapidly now tho:(
Just another liquid cooled cube :D
http://img403.imageshack.us/img403/4...0009cq1.th.jpg
hmm hey G, do you have other pics of it? like the components inside pc by pc and not just the radiator. tnx
we'd also like to know what your pc's specs are that warants a 120.3 radiator...
Ic3man, nice case :).
u're uv maniac :D.
More Pics ?Quote:
Originally Posted by _G_
Will have more pics up inb a little bit(once I get my wire management issue under control :p ) The 120.3 is a bit overkill (on any system) but I needed the length to mount it the way i did.
http://img403.imageshack.us/img403/6...0012fp5.th.jpg
system specs
amd 165 (did almost 3 on air in my last box)
ati(amd:confused: ) x1900xtx
eVGA 131-K8-NF44-AX mobo
3gb of assorted crappy valueram
maxtor atlas 10k IV 73gb ($60 refurb at tiger direct :D )
DD TDX (#5insert)
DD maze4
DDC-2 with alphacool top
7/16 masterclear
pa120.3 with 12m NMB/panflows@5v
no res or t line (syringe+PA bleedscrew :D )
:eek: nice...havent heard that one before...how long did it take to fill??Quote:
Originally Posted by _G_
love the support for the rad... :thumbsup:
That means patience... :p:Quote:
Originally Posted by _G_
Back on intel now.. :woot:
http://img239.imageshack.us/img239/2175/intelix2.jpg
