12-02-2009, 07:37 PM
bigwill68

Quote:

Originally Posted by Gaul

@ bigwill = we have similiar templates 4 q9550 @ 4.25 GH here........

anyway ? there is different : PCI Express Frequency (Mhz) ..............: 101
than 100 MHZ ?? cause im still 100

UD3R......

I got cha I changed that around now to 100 MHZ. I backed it down to 3935GHz for now but here some LinX from 4131Ghz temeplate for 4131Ghz whe.I had it up there for a week running smooth

Code:

MB Intelligent Tweaker(M.I.T.) Robust Graphics Booster ..................: Auto CPU Clock Ratio ..........................: 8 Fine CPU Clock Ratio......................: +0.5 CPU Frequency ............................: 4.13Ghz (486x8.5) Clock Chip Control Standard Clock Control CPU Host Clock Control....................: [Enabled] CPU Host Frequency (Mhz) .................: 486 PCI Express Frequency (Mhz) ..............: 100 C.I.A. 2..................................: [Disabled] Advanced Clock Control CPU Clock Drive...........................: 1000mV PCI Express Clock Drive...................: 1000mV CPU Clock Skew (ps).......................: 0ps MCH Clock Skew (ps).......................:50ps DRAM Performance Control Performance Enhance......................: Standard MCH Frequency Latch......................: Auto System Memory Multiplier ................: 2.00D Memory Frequency (Mhz) ..................: 972 DRAM Timing Selectable ..................: Manual Standard Timing Control CAS Latency Time.........................: 5 tRCD ....................................: 5 tRP......................................: 5 tRAS.....................................: 18 Advanced Timing Control [Press Enter] tRRD.....................................: 4 tWTR.....................................: 4 tWR......................................: 6 tRFC.....................................: 62 tRTP.....................................: 4 Command Rate (CMD) ......................: 2T Channel A Channel A Timings Settings Static tRead Value......................: 9 Channel B Channel B Timings Settings Static tRead Value......................: 9 Motherboard Voltage Control Load-Line Calibration.....................: Enabled CPU Vcore...............1.22500V..........: 1.343v CPU Termination.........1.200V............: 1.300V CPU PLL.................1.500V............: 1.450v CPU Reference...........0.760V............: 0.830 MCH/ICH MCH Core................1.100V............: 1.300v MCH Reference...........0.760V............: 0.800v MCH/DRAM Reference......0.900V............: 0.900v ICH I/O.................1.500V............: 1.450v ICH Core................1.100V............: 1.300v DRAM DRAM Voltage............1.800V............: 2.1v DRAM Termination........0.900V............: 0.770V Channel A Address Vref..0.900V............:Auto Channel B Address Vref..0.900V............:Auto Advanced Settings Limit CPUID Max. to 3.....................: Disabled No-Execute Memory Protect.................: Enabled CPU Enhanced Halt (C1E)...................: Disabled C2/C2E State Support......................: Disabled x C4/C4E State Support....................: Disabled CPU Thermal Monitor 2(TM2) ...............: Enabled CPU EIST Function.........................: Disabled Virtualization Technology.................: Disabled __________________

http://img690.imageshack.us/img690/9...4131ghz.th.jpg
12-03-2009, 02:31 AM
Gaul

@ bigwill68 = my little share, i'll make ddr2 1200 for 4 GB

http://img37.imageshack.us/img37/9908/425ghddr2600.jpg
12-03-2009, 01:17 PM
Hoss331

Try running blend and not just small fft.
12-03-2009, 01:36 PM
Gaul

Quote:

Originally Posted by Hoss331

Try running blend and not just small fft.

well i prefer small, which meant stability for CPU.........:)
12-03-2009, 01:48 PM
Hoss331

but not necessarily for the rest of the system since it uses virtually no ram for those tests
12-03-2009, 04:45 PM
Gaul

Quote:

Originally Posted by Hoss331

but not necessarily for the rest of the system since it uses virtually no ram for those tests

perhaps, but with that setting 24/7 no problem, and I only test with SMALL FFT

i meant ALL : VANTAGE, CB 10, CRYSIS warhead game, DIRT2, GTA4, ALL GAMES, ALL BENCHMARKING SOFTWARE, ALL :up:

why i need blend ?
12-04-2009, 01:14 AM
Hoss331

If you think its stable thats fine, personally I just dont see the point in running only small fft when blend runs the same tests along with large ffts and uses ram for the tests.
12-12-2009, 03:00 PM
Jor3lBR

Thanks to OC_Nub I have one of these Q9550 to start testing, some preliminary results on h2O:
PiFast, wPrime32 and SuperPi1m all I had time for:
http://hwbot.org/hardware/processor/...ll%20of%20fame
12-12-2009, 03:04 PM
OC Nub

Congrats, Excellent job!!!!:up:
12-12-2009, 03:10 PM
andressergio

Congrats Jor for the results on the test and Congrats Tom for that nice chip :up:
12-12-2009, 04:35 PM
Gaul

MAX on air

Q 9550 @ 4.56 GH :p:

http://valid.canardpc.com/show_oc.php?id=865863

HWBOT

http://hwbot.org/compare.do?resultId=928384
12-12-2009, 04:55 PM
OC Nub

Good work Gaul, congrats. :up:
12-12-2009, 09:30 PM
Gaul

Quote:

Originally Posted by OC Nub

Good work Gaul, congrats. :up:

thanx, well thats with 1.265 VID, i WONDER if someone had VID lower than 1.200, must 4.5 GH under < 1.4 volt.....:up:

thanx OC Nub.....:)
12-12-2009, 10:31 PM
firas

@ 3.8, thinking about the 4.0 now :rolleyes:
12-18-2009, 02:48 AM
megatron

http://i823.photobucket.com/albums/z...uxe4504to5.jpg

http://i823.photobucket.com/albums/z...uxe4254to5.jpg

GTL ref I changed to x0.640 (from 0.630) for first die (core 0 & 1).

I upped vTT to 1.24v and I bumped the vCore up 1.34375v & 1.14vNB got 450fsb stable. I did a 1:30 hr of 450 with x8 cpu multi.

I just went back to 450 x 8 and back to 1.3vCore; and I will leave it running before I tweak again.

The thing I am concerned about is 3.6Ghz with 1.3 but 3.8Ghz not stable with 1.34375v, is that normal? The cpu is rated for about 1.38v max:http://processorfinder.intel.com/det...px?sSpec=SLB8V

ASUS P5Q DLX Template :

JumperFree Configuration Settings
AI Overclock tuner: Enabled
CPU Ratio Setting: 8.5
FSB Strap to North Bridge: 333
FSB Frequency: 450
PCI-E Frequency: 100
DRAM Frequency: 5:6
DRAM CLK Skew on Channel A1: AUTO
DRAM CLK Skew on Channel A2: AUTO
DRAM CLK Skew on Channel B1: AUTO
DRAM CLK Skew on Channel B2: AUTO
DRAM Timing Control: Manual

1st Information :

CAS# Latency: 5
DRAM RAS# to CAS# Delay: 5
DRAM RAS# Precharge: 5
DRAM RAS# Activate to Precharge: 18
RAS# to RAS# Delay : AUTO
Row Refresh Cycle Time: 55
Write Recovery Time: AUTO
Read to Precharge Time: AUTO

2nd Information :

READ to WRITE Delay (S/D): AUTO
Write to Read Delay (S): AUTO
WRITE to READ Delay (D): AUTO
READ to READ Delay (S): AUTO
READ to READ Delay (D): AUTO
WRITE to WRITE Delay (S): AUTO
WRITE to WRITE Delay (D): AUTO

3rd Information :

WRITE to PRE Delay: AUTO
READ to PRE Delay: AUTO
PRE to PRE Delay: AUTO
ALL PRE to ACT Delay: AUTO
ALL PRE to REF Delay: AUTO
DRAM Static Read Control: Disabled
DRAM Read Training: Disabled
MEM. OC Charger: AUTO
AI Clock Twister: AUTO
AI Transaction Booster: AUTO
Common Performance Level [5]
Pull-In of CHA PH1: DISABLED
Pull-In of CHA PH2: DISABLED
Pull-In of CHA PH3: DISABLED
Pull-In of CHA PH4: DISABLED
Pull-In of CHB PH1: DISABLED
Pull-In of CHB PH2: DISABLED
Pull-In of CHB PH3: DISABLED
Pull-In of CHB PH4: DISABLED

CPU Voltage: 1.34375
CPU GTL Voltage Reference (0/2): 0.640
CPU GTL Voltage Reference (1/3): 0.670
CPU PLL Voltage: 1.52 (+0.02 over default)
FSB Termination Voltage: 1.24 (+0.14 over default for 45nm cpu)
DRAM Voltage: 1.9v (Using the old crucial ram like crucial anniversary so I'm not held back by Corsair xms6400c5 2x2Gb)
NB Voltage: 1.14(+0.04 over default)
NB GTL Reference: AUTO
SBridge Voltage: 1.1 or minimum
PCIE SATA Voltage: 1.5 or minimum
12-18-2009, 03:19 AM
secretworld

Hi, I'm running at 3.75Ghz/440FSB with slightly lower volts, 1.2375V bios 1.22V CPUz.
450FSB is almost undoable here, really needs massive amounts of Vcore and I gave up as 3.75 Ghz (440FSB) performs equal to 4.80 unless it's just for the numbers.
I'm on a pencil modded P5K Vanilla (for Vdroop, which is awful without the mod).
It's fully prime blend stable, but fails linX. The P5K has 3 phase power and when it gets to hot it just crashes. On a cold board the first 10 to 20 linX runs are stable. In normal use (as a DAW) this is no issue.
12-18-2009, 05:39 AM
Unrealer

Quote:

Originally Posted by secretworld

Hi, I'm running at 4.75Ghz/440FSB

440x8.5= 3.75 :p:
12-18-2009, 05:50 AM
secretworld

Quote:

Originally Posted by Unrealer

440x8.5= 3.75 :p:

ooooooopsy :D I'll edit my post. 3.75 ofcourse were did that come from??? Wishful thinking maybe?
12-18-2009, 03:57 PM
megatron

Ah you backed off 10Mhz.

http://i823.photobucket.com/albums/z.../3settings.jpg

Photo24 was 1hr5 min prime stable. I had some settings which surpassed that (maybe pic 22) with lower vTT. However I am trying settings in photo25 now. Messing with GTL ref & PLL back to 1.52v.

3.6Ghz was really easy, needed only 1.14vNB, but now I think it is wise to tweak other settings rather than vCore alone. I have tested the FSB with lower multi already needless to say, so I'm going for adjustments which effect cpu stability.
12-18-2009, 06:27 PM
Copenhagen69

what batch number should i be looking for on these?
i am going to microcenter and try to get a good one that will OC the best
12-19-2009, 01:43 AM
MrDucky

Nice memvoltage for 1081MHz megatron :O. im trying to get my Q9550 stable @ 4.0GHz 1.2v :)
12-19-2009, 01:59 AM
megatron

Quote:

Originally Posted by MrDucky

Nice memvoltage for 1081MHz megatron :O. im trying to get my Q9550 stable @ 4.0GHz 1.2v :)

Maybe a bit low? Timings are loose. I did test it with a lower multi previously.

Result of more testing:

http://i823.photobucket.com/albums/z...2hr482hr54.jpg
First I lowered GTL ref for first core to x0.620
went from 1hr5 prime stable to 2hr48 prime stable (or unstable if u like)
Upped vcore from 1.34375v to 1.35v
increased stable time by 6min.

Tried x0.610 and right after I "tested" a register dump in core temp it errored on core 1 at 2min in.
Back to x0.620 and now testing pll 1.52->1.56v.
12-19-2009, 01:51 PM
MrDucky

well my vid is 1.1375 so 1.2v is ok it stopped after 1 hour en 58 minutes :/ error core 2 maybe higher vtt is the key. does annyone have some tips where is should look after with Quad OCing :P?

I have a DFI LP DK P45 T2RS+.

Goodluck getting your cpu stable :)
12-20-2009, 08:32 AM
milladog420

Awesome to see all this. Q9550 is a great chip...overclocks nice and runs anything you throw at it.
12-20-2009, 01:30 PM
MrDucky

http://i45.tinypic.com/11h58oo.png

Some MHz testing not stable though but hot... 70 degrees in prime 95 :X
