12-05-2009, 12:34 PM
Raiden

Quote:

Originally Posted by josk1

here and here you'll find what you want!

Thanks josk1 you know any European store that sells this?

Because im from portugal ... sorry about the offtopic

Waiting to see the some progress in this project:up:
12-05-2009, 12:41 PM
josk1

no I don't, but sidewinder does international shipment... but I've no idea about the price then...

HazChem: can you tell me what's the difference between the fits with the green o-ring and the blue ones???
12-05-2009, 01:03 PM
HazChem

Quote:

Originally Posted by aka_GK

nice fittings, subd ;)

Mine has the same fit :shrug:

Quote:

Originally Posted by Raiden

Thanks josk1 you know any European store that sells this?

Because im from portugal ... sorry about the offtopic

Waiting to see the some progress in this project:up:

Quote:

Originally Posted by josk1

no I don't, but sidewinder does international shipment... but I've no idea about the price then...

HazChem: can you tell me what's the difference between the fits with the green o-ring and the blue ones???

Thanks guys.

No difference. I was hoping they'd be a little bit thicker but as you can see from the pics, they aren't.

I've made progress assembling the parts onto the board. Will post soon.

I'm trying to figure out how to route all the tubing at the moment.
12-05-2009, 02:38 PM
josk1

Quote:

Originally Posted by HazChem

Thanks guys.

No difference. I was hoping they'd be a little bit thicker but as you can see from the pics, they aren't.

I've made progress assembling the parts onto the board. Will post soon.

I'm trying to figure out how to route all the tubing at the moment.

shouldn't be a problem with all that room you have in there :D
12-06-2009, 08:24 AM
HazChem

So installing the mobo blocks took me most of Saturday. I definitely didn't plan on that!

Excuse the oranginess (sp?) on the next couple of pics. I'll come back later and fix the exposure!

http://i1021.photobucket.com/albums/...12_05_3321.jpg

http://i1021.photobucket.com/albums/...12_05_3322.jpg

http://i1021.photobucket.com/albums/...12_05_3323.jpg

http://i1021.photobucket.com/albums/...12_05_3324.jpg

http://i1021.photobucket.com/albums/...12_05_3329.jpg

Opened it up to see the greased caked on and hard!
http://i1021.photobucket.com/albums/...12_05_3330.jpg

This one took me the longest.
http://i1021.photobucket.com/albums/...12_05_3331.jpg

But I think I did a pretty good job!
http://i1021.photobucket.com/albums/...12_05_3332.jpg

http://i1021.photobucket.com/albums/...12_05_3333.jpg

http://i1021.photobucket.com/albums/...12_05_3337.jpg

Putting on the thermal pads.
http://i1021.photobucket.com/albums/...12_05_3338.jpg

http://i1021.photobucket.com/albums/...12_05_3339.jpg

http://i1021.photobucket.com/albums/...12_05_3344.jpg

Lining up the block which also took quite some time.
http://i1021.photobucket.com/albums/...12_05_3341.jpg

http://i1021.photobucket.com/albums/...12_05_3342.jpg

I was curious to look at what the inside of the block looked like and to my surprise, there was oil all over the place! I opened up all the blocks and found contamination.
http://i1021.photobucket.com/albums/...12_05_3345.jpg

http://i1021.photobucket.com/albums/...12_05_3346.jpg

I am so glad I got a chance to clean it out before I ran water through it!
http://i1021.photobucket.com/albums/...12_05_3347.jpg

http://i1021.photobucket.com/albums/...12_05_3348.jpg

http://i1021.photobucket.com/albums/...12_05_3349.jpg

http://i1021.photobucket.com/albums/...12_05_3350.jpg

http://i1021.photobucket.com/albums/...12_05_3351.jpg

http://i1021.photobucket.com/albums/...12_05_3352.jpg

http://i1021.photobucket.com/albums/...12_05_3354.jpg

http://i1021.photobucket.com/albums/...12_05_3355.jpg

http://i1021.photobucket.com/albums/...12_05_3356.jpg

http://i1021.photobucket.com/albums/...12_05_3357.jpg

http://i1021.photobucket.com/albums/...12_05_3359.jpg

Here's what I've already started for today.
http://i1021.photobucket.com/albums/...12_06_3362.jpg

http://i1021.photobucket.com/albums/...12_06_3363.jpg

I'm hoping to get all the tubing installed and mounted and then get the radiator installed.
12-06-2009, 09:06 AM
aka_GK

Hey, is it primochill uv blue tubes?
12-06-2009, 06:21 PM
Liderc

Always love short tubing routes, keep it simple and short like your first bend there.
12-06-2009, 06:46 PM
HazChem

Quote:

Originally Posted by aka_GK

Hey, is it primochill uv blue tubes?

Yah, it is. Looks much better that I could capture it on here!

Quote:

Originally Posted by Liderc

Always love short tubing routes, keep it simple and short like your first bend there.

Thanks, that is my goal Liderc... :) Lucky for me that that was the toughest one to get without introducing a kink.
12-06-2009, 07:34 PM
HazChem

My progress today:

http://i1021.photobucket.com/albums/...12_06_3364.jpg

http://i1021.photobucket.com/albums/...12_06_3365.jpg

http://i1021.photobucket.com/albums/...12_06_3366.jpg

Prepping the fans for a paint job.
http://i1021.photobucket.com/albums/...12_06_3368.jpg

http://i1021.photobucket.com/albums/...12_06_3369.jpg

Masked the fans and was ready to go outside to paint but it was misty and 50 degrees out... :( A bit too cold and wet to do a proper paint job. Oh well, I'll do it later this week.
http://i1021.photobucket.com/albums/...12_06_3370.jpg

Reservoir location may change after I get the rad and mobo installed but this is a good location for now.
http://i1021.photobucket.com/albums/...12_06_3371.jpg

http://i1021.photobucket.com/albums/...12_06_3372.jpg

Started the sleeving and had some fun taking these pics.
http://i1021.photobucket.com/albums/...12_06_3375.jpg

http://i1021.photobucket.com/albums/...12_06_3376.jpg

http://i1021.photobucket.com/albums/...12_06_3377.jpg
12-06-2009, 09:16 PM
Petrucci_M3

Love it dude, nice work and the color scheme is excellent. Seems we will be doing both an i7 and Cosair WC build, such a killer combo.

SUBBED btw :)
12-07-2009, 04:06 AM
josk1

nice !!!

i love the fact that you paid attention to the color matching of every detail...

looks great! keep it up!
12-07-2009, 04:46 AM
Nem

Looking very nice indeed!

But then I would say that with this case and sleeving colours :p:
12-07-2009, 06:00 PM
HazChem

Quote:

Originally Posted by Petrucci_M3

Love it dude, nice work and the color scheme is excellent. Seems we will be doing both an i7 and Cosair WC build, such a killer combo.

SUBBED btw :)

Thanks! 800D is a popular choice these days but Corsair really hit a home run with their first case. It begs for a watercooling setup.

Quote:

Originally Posted by josk1

nice !!!

i love the fact that you paid attention to the color matching of every detail...

looks great! keep it up!

Quote:

Originally Posted by Nem

Looking very nice indeed!

But then I would say that with this case and sleeving colours :p:

Thanks guys. I'm glad MDPC carries these two blues. I think they go really well together.

Here are a few more pics.
http://i1021.photobucket.com/albums/...12_07_3385.jpg

http://i1021.photobucket.com/albums/..._07_3386-1.jpg

http://i1021.photobucket.com/albums/..._07_3389-1.jpg
12-07-2009, 06:40 PM
dingdong555

Very nice sleeving mate!
12-08-2009, 04:19 AM
kgtiger

Excellent work there HazChem, thanks for adding the extra photo's of your sleeving to the sleeving guide.
After all, the end of the sleeving really is the business end of the deal, you either nail it or it all falls apart right there.

Personally, I feel you have nailed! it. :yepp:

Well done mate its all coming together nicely. :up:
12-08-2009, 06:27 PM
HazChem

Quote:

Originally Posted by dingdong555

Very nice sleeving mate!

Thanks! You're build has given me inspiration and plenty of great ideas! What you've done in your latest post is sweet!

Quote:

Originally Posted by kgtiger

Excellent work there HazChem, thanks for adding the extra photo's of your sleeving to the sleeving guide.
After all, the end of the sleeving really is the business end of the deal, you either nail it or it all falls apart right there.

Personally, I feel you have nailed! it. :yepp:

Well done mate its all coming together nicely. :up:

Wow, thanks!! You're work is keeping me motivated, keep it up!
12-10-2009, 09:40 AM
CptDreadFlint

Awesome job on the Freezer block on the RIIE! (Did a little De Ja Vue-ing)
Did you manage to mount the ROG chip back on board?

Still trying to find a slick way to mount mine.

Your sleeving came out looking swa-eeet! Grand Bleu and Aquamarine goes so well together.

EDIT: I see the ROG chip. Looks to be sitting on top of the POM part of the Freezer. Got more pics? :D
12-12-2009, 08:55 AM
HazChem

Took a day off yesterday and made a little bit of progress.

I got the fans and the block painted. The weather didn't cooperate so a one day job took me all week...
http://i1021.photobucket.com/albums/...12_11_3394.jpg

http://i1021.photobucket.com/albums/...12_11_3396.jpg

Putting the fans back together was a PITA! The stupid little c-clips didn't want to go back on. Grrr...
http://i1021.photobucket.com/albums/...12_11_3398.jpg

http://i1021.photobucket.com/albums/...12_11_3400.jpg

http://i1021.photobucket.com/albums/...12_12_3415.jpg

http://i1021.photobucket.com/albums/...12_12_3412.jpg

The screws I bought to mount the rad and fans to the top of the case were too long. Being lazy and not wanting to go back to HD to buy shorter screws, I did the next best thing. Kudos to whoever invented the Dremel. :)
http://i1021.photobucket.com/albums/...12_11_3402.jpg

Moments later...
http://i1021.photobucket.com/albums/...12_11_3403.jpg

Remounted the reservoir.
http://i1021.photobucket.com/albums/...12_12_3409.jpg

A closeup of the ROG mounted on the waterblock. I mounted it using the original sticky thermal pad that was on the ROG block. Very convenient and works!
http://i1021.photobucket.com/albums/...12_12_3410.jpg
12-12-2009, 09:14 AM
josk1

gotta sleeve the ROG cables dude !!! ;)

looks great !
12-12-2009, 09:52 AM
TadZilla

Great looking build!
12-12-2009, 10:03 AM
GregSG

Nice!

I like ur fans hahas!
12-12-2009, 01:30 PM
Seu

Very nice work , ( hidden subscribed :D ) keep going ! :up:
12-12-2009, 09:02 PM
Antioch

Glad the fans turned out well.

Can you give more info on taking apart and reassembling the fans? Also, how to they perform and sound with the coat of paint on the blades?

I'm trying to decide between GTs painted black of S-Flexes at the moment. The SFLEXes perform better at lower RPMs, but the GTs perform better at higher RPMs (I factor sound and air-movement heavily).
12-13-2009, 07:57 PM
HazChem

Quote:

Originally Posted by josk1

gotta sleeve the ROG cables dude !!! ;)

looks great !

Darn, you noticed! My fingers are sore from all the sleeving I did on the power supply that I am going let them heal up before I finish the rest of them... I know, wimp... :p:

Also, I almost used up the sleeves so I have to order more to get all the cables done...

Quote:

Originally Posted by TadZilla

Great looking build!

Thanks Tad. It's coming along!

Quote:

Originally Posted by GregSG

Nice!

I like ur fans hahas!

Thanks!!

Quote:

Originally Posted by Seu

Very nice work , ( hidden subscribed :D ) keep going ! :up:

Thanks!

Quote:

Originally Posted by Antioch

Glad the fans turned out well.

Can you give more info on taking apart and reassembling the fans? Also, how to they perform and sound with the coat of paint on the blades?

I'm trying to decide between GTs painted black of S-Flexes at the moment. The SFLEXes perform better at lower RPMs, but the GTs perform better at higher RPMs (I factor sound and air-movement heavily).

I followed this thread. I didn't get to listen to them at full speed before I painted them so I can't compare but they sounded pretty quiet after the paint job.

I went with the GTs because of their high static pressure and excellent performance up to 1800 RPM. I wanted the headroom for when the system got going. They are perfect for the rad.
12-13-2009, 08:16 PM
HazChem

Yesterday, I put everything together to leak test it by connecting pump to an isolated power source and so far nothing leaked after a couple of hours!! Woohoo!!
http://i1021.photobucket.com/albums/...12_12_3417.jpg

http://i1021.photobucket.com/albums/...12_12_3423.jpg

http://i1021.photobucket.com/albums/...12_12_3424.jpg

http://i1021.photobucket.com/albums/...12_12_3425.jpg

http://i1021.photobucket.com/albums/...12_12_3427.jpg

So I connected everything up in preparation for final cable routing and then hit the power button and...
http://i1021.photobucket.com/albums/...12_12_3430.jpg

I got nothing!!! Grrr!!!!

No beeps, nothing!! Mobo won't post. What happens is that when I switch on the power supply, the ROG and all the mobo buttons light up. But when I press the Start button on the mobo, it turns on for a brief 1/2 second and then it all shuts down. I've spent hours trying to figure it out. Apparently it happens when there is a short or something. It worked just fine prior to the project so I don't know what could have happened. Hmph.

I thought "oh crap" I messed up the power supply. But it isn't that since I connected it up to a another pc and it works fine.

This sucks @$$!!

Project on hold but this will give me time to order more sleeving and enjoy Christmas!!

If you have any ideas before I RMA it, I'd be happy to hear it... I'll give Asus a call and try to RMA it.
