05-20-2008, 11:39 AM
BrowncoatGR

If that pic of the heatspreader is real the die must be monstrous.
05-20-2008, 11:41 AM
Shintai

Quote:

Originally Posted by BrowncoatGR

If that pic is real the die must be monstrous.

Ever tried look under a IHS before? Lets just say the 2 things are wastly different.
05-20-2008, 11:50 AM
BrowncoatGR

Quote:

Originally Posted by Shintai

Ever tried look under a IHS before? Lets just say the 2 things are wastly different.

True but the bigger the die the bigger the heatspreader usually. Besides all rumours point to a massive chip regardless. Anyway i fixed the wording in my OP.
05-20-2008, 11:55 AM
biftek.

That's so fake, the PCB isn't nearly long enough :rofl::ROTF:

http://img242.imageshack.us/img242/2893/humorkb5oc6.jpg
05-20-2008, 12:07 PM
natedog420

Quote:

Originally Posted by biftek.

That's so fake, the PCB isn't nearly long enough :rofl::ROTF:

http://img242.imageshack.us/img242/2893/humorkb5oc6.jpg

nice photochop but i dont think we need pics like that you may think its fake but others think its real.
05-20-2008, 12:09 PM
Origin_Unknown

the original pic.... wowza, that thing is bloody huge.
05-20-2008, 12:21 PM
Tim

Quote:

Originally Posted by RaZz!

to be able to upload them in a proper resolution is different to not want to upload them in a proper resolution.

it seems to me that the original pic is larger, but the one who did that screenshot resized the preview window (which resizes the original image to fit the preview window) to conceal details on the die or smth. maybe because of being under nda, who knows.

i'd also say it's legit. if the rumored specs are true this one will be some heavy beast :)

And we have a winner! Ofcourse that's the reason why they didn't post high res shots. Not everyone knows how to mask a PCB/Chips properly. ;)
05-20-2008, 12:22 PM
AliG

Quote:

Originally Posted by DilTech

Thermal Pads still on the ram. Take off the heatsink to any gpu stock and you'll find that same white stuff on your ram or heatsink. ;)

I dunno, those definitely look like they were digitally edited to be whited out, my bet is that was done so that people don't know the final spec of the memory being used until nvidia reveals it themselves
05-20-2008, 12:25 PM
triple_A

Quote:

Originally Posted by biftek.

That's so fake, the PCB isn't nearly long enough :rofl::ROTF:

http://img242.imageshack.us/img242/2893/humorkb5oc6.jpg

rofl, kinda reminds me of this
http://i211.photobucket.com/albums/b...astu7abtz8.jpg

Sorry for the OT :D
05-20-2008, 12:43 PM
Luka_Aveiro

Quote:

Originally Posted by AliG

I dunno, those definitely look like they were digitally edited to be whited out, my bet is that was done so that people don't know the final spec of the memory being used until nvidia reveals it themselves

Just termal pads buddy, had to deal with them when removed 3 8800GTs stock coolers :p:
05-20-2008, 12:52 PM
RaZz!

Quote:

Originally Posted by triple_A

rofl, kinda reminds me of this
http://i211.photobucket.com/albums/b...astu7abtz8.jpg

Sorry for the OT :D

lol, this pic made me laugh so hard :D
05-20-2008, 01:15 PM
dunn2953

i dont understand why manufacturers are pushing for dual core GPUs, all this will bring is a loss of high end performance due to scaling issues.
05-20-2008, 02:10 PM
XS Janus

http://smiliesftw.com/x/bigbowrofl.gif

Incredible pics. Made me ROOOOLLLLL!
Thanx!
05-20-2008, 02:22 PM
biftek.

Quote:

Originally Posted by triple_A

rofl, kinda reminds me of this
http://i211.photobucket.com/albums/b...astu7abtz8.jpg

Sorry for the OT :D

Awwww think of all the performance loss due to the PCI interface :(
05-20-2008, 02:35 PM
Decami

Quote:

Originally Posted by AliG

Heh, nvidia first thumbs its nose at ati for making the r700 a dual gpu card because gt 200 is a single gpu card, and now they've decided to stop making single gpu high ends
pictures are kinda small though, can anyone with and 8800gtx/ultra confirm that this isn't simply a g80 gpu?

Quote:

Originally Posted by dunn2953

i dont understand why manufacturers are pushing for dual core GPUs, all this will bring is a loss of high end performance due to scaling issues.

I'm thinking the reason for this is because they want to dominate the physics market as well now, cause they are so mad at Intel. and dual GPU cards are really the way to go for that. That and I think they are starting to hit performance walls with their single chips now, not performance walls as in cant go any faster/higher, but performance wall in a marketing since, the better the single chip gets the longer it takes to improve the next go around, multi gpu's make this process much easier.
05-20-2008, 02:38 PM
Tim

Quote:

Originally Posted by AliG

I dunno, those definitely look like they were digitally edited to be whited out, my bet is that was done so that people don't know the final spec of the memory being used until nvidia reveals it themselves

lol, and yet leave all sensitive information on every other chip and label so that it can be traced back and the leak kicked out of nVidia's books for good and sued for breaking NDA?

No chance. Those are thermal pads, you would have known that if you ever removed a heatsink. :)
05-20-2008, 02:40 PM
dinos22

Quote:

Originally Posted by biftek.

That's so fake, the PCB isn't nearly long enough :rofl::ROTF:

http://img242.imageshack.us/img242/2893/humorkb5oc6.jpg

yup this is pretty close to final design i reckon :rofl::up:
05-20-2008, 03:32 PM
Hornet331

Quote:

Originally Posted by Tim

lol, and yet leave all sensitive information on every other chip and label so that it can be traced back and the leak kicked out of nVidia's books for good and sued for breaking NDA?

No chance. Those are thermal pads, you would have known that if you ever removed a heatsink. :)

yup and sometimes its really hard to get rid of them -> deepfreezer ftw. :D
05-20-2008, 07:22 PM
gojirasan

Quote:

Originally Posted by Tim

No chance. Those are thermal pads, you would have known that if you ever removed a heatsink.

Actually my vid card was sitting on my desk without the heatsink when I asked about those white blobs in the photo. I just didn't recognize them as thermal pads (assuming they really are thermal pads). I did appreciate the answer to my query though. I always try to remove those slimy gauze things before they harden up like clay in a kiln. Evil little things.
05-20-2008, 08:33 PM
cookerjc

Quote:

Originally Posted by Linchpin

I have a feeling this is fake but time will tell.

it is not fake, just compare it with mechanical drawing leak earlier.

Updated with a die pic

http://en.expreview.com/img/2008/05/21/GT200-core_1.jpg

link:shocked:
05-20-2008, 09:19 PM
Mk

Humm it kinda looks like the 3D drawing so it might be true but then agin if teh 3D drawing was fake then they are both fake :p:
05-20-2008, 11:44 PM
Jack

Quote:

Originally Posted by ALI

Heh, nvidia first thumbs its nose at ati for making the r700 a dual gpu card because gt 200 is a single gpu card, and now they've decided to stop making single gpu high ends

Quote:

Originally Posted by Shintai

Asuming you trust the source. And that would be like believeing anything.

Well with Intel's Larrabee is going in that same directions, why shouldn't Nvidia take the multicore path?
05-20-2008, 11:55 PM
The0men

Quote:

Originally Posted by AliG

I dunno, those definitely look like they were digitally edited to be whited out, my bet is that was done so that people don't know the final spec of the memory being used until nvidia reveals it themselves

Yer gotta go with you on this one.

yer seen loads of the thermal pads, but why not remove, and its a pristine white, which considering the quality of the photo would be hard to do unless you digitally whited out afterwards.

Edit: Then again why white out only some of them, all the chips would be the same, and not like you can make anything out anyway.
05-21-2008, 12:44 AM
Shintai

Quote:

Originally Posted by Jack

Well with Intel's Larrabee is going in that same directions, why shouldn't Nvidia take the multicore path?

Each shader cluster/pipe is basicly a core. We have had that for ages and ages. What people talk about is multiple chips sharing memory and such. With Larabee you have the same setup. Just with IA32 minicores on a single shared die with a raster/rop/tmu frontend. The minicores will only replace shaders.
05-21-2008, 05:50 AM
cantankerous

I can't wait to see what the cooler is going to be for this. I hope it is incredibly efficient at keeping things cool while still maintaining relatively low volume levels. I find my 8800 Ultra quite quiet at 100% fan speed. I hope I can say the same for this new card.
