Thought I would add my information on my 3841... from Microcenter Retail location in MI. All information in in the specs below.
Printable View
Thought I would add my information on my 3841... from Microcenter Retail location in MI. All information in in the specs below.
Below where? not everyone has sigs turned on, you know :rolleyes:Quote:
Originally Posted by Terlcartman
Sorry for the newby mistake I did not even know you could turn them off. As you can see this is my 3rd post. I have copied the info from my sig below.
i7-920 (3841A437 Microcenter) Gigabyte EX58-UD5 F5g BIOS
Corsair XMS3 6GB DDR3-1600 (PC-12800) CL9
CoolMaster V8, Antec 1200, Enermax Galaxy 1Kw
BFG GeForce 295 GTX
Current OC: 19x200 3.8ghz, turbo off, HT on, Vcore: BIOS 1.33125, 1.248v load, 1.296v idle
All other volts auto
3600mhz QPI (Auto), 3200mhz Uncore (Auto)
1600mhz memory (Auto) @ 9-9-9-24-1T
LinX 20 Stable with Gigabyte F4 BIOS or F5g BIOS
Real Temp 3.0 max 81C
Vista 64bit Dell 2407 24"
Best LinX 20 Stable OC: 20x191 4.011ghz, turbo on, HT on
Vcore: BIOS 1.375, 1.328v load, 1.344v idle
VTT/QPI 1.335, 3438mhz QPI X36, 17X Uncore
1528mhz memory Using 8X and XMP Profile1 @ 9-9-9-24-2T with 6GB
VDRAM 1.64, QPI PLL 1.4,
Real Temp 3.0 max under load 89C using F5g BIOS
Regarding the batches from Micro Center, since they have one of the lowest list price for the 920s, so it seems like 3841A431 or possibly 3841A383
are to be expected?
That is unless you know someone there who can hand pick the retail box or somehow you luck out.
I am not sure what else they have in stock batch wise as I really did not know anything about the batch numbers when I bought the chip. Actually I knew nothing about overclocking except that the sales person, who was excellent, told me that people were having great success oc'ing this chip. I would run over to the store and check but it is about 40 minutes away. If I go back for any reason I will take a look and report back. Based on what I have read and my own experiences the 3841 seems to be a good bunch. As you said Microcenter has one of the best prices and the day I went to think about building a machine they had a specific sale for people building computers, so I got everything except the MB for a good bit less than retail and at or below what I could find quickly on the web.Quote:
Originally Posted by Savuti
I am running a 3841 from microcenter, just picked it up today. WAY better than may 3839. My 39 would not prime 4.2 8 thread at all, no matter the voltage. I am prime blend 4.2 8 thread @ 1.475v on this 41. So far so good, 70C load with HT....not too bad. I will see if I can back off the vcore after a few hours of prime.
my microcenter 3841A437 wont prime for more than 5 seconds on any voltage. i'm starting to think something else is the culprit though. my psu is obviously not powering my system enough because my pc shuts off when i try to game. time for that corsair 620hx i guess..
I have been able to Prime 95, either blend or small FFTs for what ever the stock amount of time is at the voltage above multiple times until I got LinX which seemed to drive the cores harder, definitely drove the temps higher and would crash/BSD much faster. Like you said it sounds like something else is causing your issue besides the i7.
yes, an image of a list... what the hell is the difference, might i ask? its sorted by week and batch, which is the entire point of the thread... And yes, I can revert the spreadsheet to points before the sorting, however that erases all the legit edits after... Anyways, like I said, I will not bother with this anymore, as it takes up alot of time to enter all this stuff manually.Quote:
Originally Posted by loonym
Anyone want to take over? I would but I am pretty new here...
mine is 3839a597
i am using ms eclipse and heres the setting
Base Clock - 190
Turbo Boost - Enable
C State - Disable
Memory Ratio - 4 or 1520 Mhz
CPU Voltage - +0.00v
QPI - +0.160
CPU Pll - Auto
Dram Voltage - 1.65v
IOH Voltage - 1.1v
ICH Voltage - 1.52v
CPUZ and MSI D.O.T says 1.104v vcore ?
http://img.photobucket.com/albums/v6...3/bart4gi7.jpg
http://img.photobucket.com/albums/v6...i7pcmark05.jpg
Maybe we can get a bunch of folks and each take one week of duty, passing the sheet around via email or something? Maybe then we could post the results on gspreadsheet or something, each time copying and pasting into the sheet? I dunno, I hate to see this die.
spread sheet is completely frak'd now
Here we go, highest clock to lowest. If you feel you have been misrepresented let me know. Also if I missed you or anyone let me know, easily updated. If needed we can always start a new thread and have a mod move all posts to it so we can keep the top updated.
EDIT: SEE BELOW.
hey if anybody wants to add my load temps to mine here they are. They dont get any hotter over time, the GTX480 does a great job of keeping temps in check from beginning to end of a stress test.
http://img.techpowerup.org/090208/Capture039.jpg
Ok, updated for you Chicken.
http://i487.photobucket.com/albums/r...chtrackerx.jpg
After dl'ing the data from google a few days ago, I tried playing with it so I could see trends...it was challenging especially since I'm not all that used to excel graphs. I was trying to do a 3-d column chart that would have different voltage settings along the front and then columns with each attained speed on the y so that we could see the 'king' (highest speed at each voltage). But it didn't work. :(
I was doing a graph as well but I think a list is enough, browse though and see what you can find.Quote:
Originally Posted by headala
Maybe after there is a bit more data a graph would work better.
Quote:
MisterMagoo;3637274]Ok, updated for you Chicken.
You sure, I still don't see my temps added :p:
I had to refresh a couple times, clear your cache and it will show. I will have to start renaming the image so this isnt a problem.Quote:
Originally Posted by Chicken Patty
got it, thanks dude :up:Quote:
Originally Posted by MisterMagoo
Reference this post to for updated/correct voltage readings and 4GHz oc.Quote:
Originally Posted by MisterMagoo
Gotcha, all good.Quote:
Originally Posted by The Nemesis
I will start to update at the end of the days, to keep it simple.
http://i487.photobucket.com/albums/r...trackerx_1.jpg
This 3841 is a keeper....
Edit..lol..I guess there are no thumbs for attachments here...
^ what are you cooling with, thats a great clock!
