if ure using vcore set to 1.445 and LLC 100%
ure close to 1.5v bud on load
u can still use LLC 75% but u need to be accurate. i use this up to 5.0 at 1.52v
with u raising vssa etc for mere 2133..
still dont think ure stable.
Printable View
if ure using vcore set to 1.445 and LLC 100%
ure close to 1.5v bud on load
u can still use LLC 75% but u need to be accurate. i use this up to 5.0 at 1.52v
with u raising vssa etc for mere 2133..
still dont think ure stable.
Well we will find out in a few hours. I started Prime95 this morning before work and it was still running after an hour when I left. Will see if it's still running when I get home.Quote:
Originally Posted by cstkl1
Also, if you look in the Xtreme Bandwidth section you will see Chew had to raise his vccsa from stock for his 8-9-8-24-1T testing with my same set of memory, same MB and cpu. This is the first 12 hour stretch I have gone without any random blue screen 124bsods since I've reaised vccsa to 1.11v.
I am going to hook my mutlimeter up to the Board tonight to see actual vcore with LLC100%. CPUZ is reporting 1.45v when bios is set to 1.445v
Can you explain why plz?Quote:
Originally Posted by FlanK3r
With SP1 you get access to AVX instruction in windows, therefore you are able to stress your CPU beyond prime levels using LINX with AVX, otherwise ( without avx ) you should stick with prime, because it will stress your CPU more then LinX. You can confirm this using a killwatt or one of those nice piece of softwares that read CPU wattsQuote:
Originally Posted by ChaosAD
Thanx for the reply, didnt know about AVX in SP1 :up:Quote:
Originally Posted by st0ned
Beautiful rig! :up:Quote:
Originally Posted by deachus
What kind of issues/performance hit would I run in to using pciex16_1 and 2 for SLI instead of the suggested 1 and 3? I did not budget my space for using 1 and 3 :shakes:.
Also, are either (both?) of the molex 4 pin power connections on the board required, and what do they do? I read conflicting information that they are for SLI / Tri-SLI or are for USB power...
Thanks,
-sf
Use the two 4 pins, you dont loose anything in doing so... Not sure thought what they feed.
slot's 1 and 2 will give you SLI/CF using the NF200 bridge. You will take a sligth performance hit. 5% ?? due to the lag add by it.
I've got SLI 580s running in slots 1 & 3 without using either of the molex's on the board without any probs.
G.Skill RipjawsX 2133C8 @ 2133 6-9-6-24
http://i458.photobucket.com/albums/q.../21336-9-6.jpg
Well, I should have my board tomorrow. I'm excited and disapointed at the same time. No way to use my soundcard with trifired cards.:mad:
May have to send it back and get a UD7 with a waterblock for the board.:shakes:
If the soundcard is a deal breaker why did you order the board to begin with? Should have been obvious if using 3 video cards there would be no room for the soundcard.Quote:
Originally Posted by Devil_Dog
Originally was going to use 2 cards but a 3rd fell into my hands after I ordered.Quote:
Originally Posted by Praz
Anyone knows how to fix issues between maximus 4 extreme and amd drivers?I keep getting BSOD while opening cpu-z vga tab,aida64 or aisuite,on windows7 64-bit...This happens only on amd vga's...
Also some cas6 testing with my new board :D
http://img200.imageshack.us/img200/6...2c6aida.th.png
Uploaded with ImageShack.us
full w7 install here, xp soon to come. . .
http://i52.tinypic.com/23kvfw4.jpg
http://i51.tinypic.com/315bara.jpg
what vga are you running :)?
Looks good :up:... is that a new 2600K? What batch?Quote:
Originally Posted by l0ud_sil3nc3
@ sil3nc3 and Alex-Ro...
What kind of Vccio, Vccsa and Vdimm are you running for that kind of bclk?
Quote:
Originally Posted by PolRoger
one of msimax's chips I bought last week, and a very nice one
L041C108
# 3832
the best sandy I have played with for sure and I am still looking for a better one
for now a GTX 285, but I have an unlocked 6950 and a bnib Asus GTX560 Ti DCUII that I am thinking about throwing in to test, but no problems with either the 6950 or the GTX285 so I am unsure what your issue stems from.Quote:
Originally Posted by Alex-Ro
Hmm,told ya,cpu-z keeps crushing my systen when i go to vga tab.Also i cant get aisuite to work properly,even if i applied that patch...What the name of the tool that displays voltages ?I was running 1.1 SA and 1.15 VCCIO.Ill try harder tomorrow,with proper tuning i hope ill reach at least 108 BCLK.
turn down sa to 1.0 and make sure you have the IMEI driver installed, that is why you probably don't see aisuiteII.Quote:
Originally Posted by Alex-Ro
Well thing is that i have management engine installed :)
Your ram is probably unstable......AMD's drivers are sens to unstable ram clocks.Quote:
Originally Posted by Alex-Ro
Thought so at first,but primming with 896K fft and memtest did not reveal anything...In my other OS,xp 32 bit i have no problems at all :) Also,could someone tell me how can i use offset voltage on maximus?Apreciated.
I would steer away from using offset voltage and just stick to manual voltage as it did not work that well, usually overvolting much higher than what was set or needed.Quote:
Originally Posted by Alex-Ro
